RCS Audio-Systems RAB-014 B 19 ? rack, 14U

The RAB-014 B is a high-quality 48,3 cm ( 19 inch ) floor-standing rack cabinet from the professional RAB series, specifically developed for use in PA systems, audio installations, and other technical infrastructures. With 14 rack units, it provides ample space for mounting equipment, module carriers, and accessories in accordance with DIN 41494, the industry standard for 19-inch systems.

Constructed from welded sheet steel, the cabinet offers exceptional rigidity and durability. Its surface is powder-coated in RAL 7035 (light grey) for a clean, technical look that fits seamlessly into studios, control rooms, or public environments.

Removable side panels greatly simplify installation and cabling. An optional lockable plexiglass door with an integrated cylinder lock offers both security and visibility. The cabinet can be equipped with the optional RFF-200 active fan unit to ensure proper ventilation.

A lockable RBP-100 bottom plate with a foam-sealed cable exit enables clean and dust-protected cable management. For heavy-duty components, RGL-525 sliding rails are recommended. A wide range of accessories for Hi-Fi and non-48,3 cm ( 19 inch ) equipment—such as shelves, pull-out trays, and drawers—is also available.

Technical Details:

Model:
– RAB-014 B

System Standard:

– 48,3 cm ( 19 inch ) according to DIN 41494

Rack Units (RU):

– 14

Total Height:

– 707 mm

Usable Installation Height:

– 630 mm

Total Depth:

– 600 mm

Installation Depth:

– 530 mm

Total Width:

– 570 mm

Weight:

– 30.0 kg

Material:

– Welded sheet steel, powder-coated

Color:

– RAL 7035 (light grey)

Key Features:

– Removable side panels
– Optional lockable plexiglass door
– Optional RFF-200 active fan unit
– RBP-100 sliding bottom plate with foam cable exit
– Optional RGL-525 sliding rails for heavy devices
– Extensive accessory range for non-48,3 cm ( 19 inch ) components
Type: RAB-014B
