PLANET 8-Port PoE+ Managed Switch XGS-6320-8UP4X
|
1.300,11 EUR |
|
|
( 1.547,13 EUR incl. VAT ) ≈ £1,120.69 | ≈ $1,474.32 plus delivery charges: 53,00 € |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1198245 |
|---|---|
| Mfg Part No: | XGS-6320-8UP4X |
| UPC/EAN: | 4711605287593 |
| Weight: | 0.12 kg |
Product information for Planet XGS-6320-8UP4X:
The PLANET XGS-6320-8UP4X is a robust Layer 3 managed switch designed for high-performance networking environments. With 8 10GBASE-T ports and 4 10GBASE-X SFP+ ports, it delivers 10Gbps full-speed connectivity for demanding applications such as Wi-Fi 7 access points, surveillance systems, and enterprise networks. It supports IEEE 802.3bt PoE++ Type 4 with up to 95W per port and a total PoE power budget of 420W.
The switch offers extensive Layer 2/3/4 features, advanced PoE management, IPv4/IPv6 routing, and secure network controls, making it the perfect backbone for smart cities, enterprise cores, and future-ready infrastructures.
Technical Summary:
Network Interfaces:
- 8x 10GBASE-T RJ45 (100Mbps to 10Gbps), IEEE 802.3bt PoE++
- 4x 10GBASE-X SFP+ (1G/2.5G/10G fiber modules)
- 1x RJ45 Console Port (RS232)
PoE Power Supply:
- IEEE 802.3bt Type-4 compliant, up to 95W per port
- Total PoE budget: 420W
- Power modes: End-span, Mid-span, Force
- Features: PoE Scheduling, PD Alive Check, PoE Extend Mode (160m), LLDP Neighbors
- Real-time power management & per-port controls
Switching:
- Switching Capacity: 240Gbps
- Throughput: 178.57Mpps
- MAC Table: 32K
- Buffer: 32Mbit
- Jumbo Frames: 10K
- 3 Smart Cooling Fans
Layer 3 Routing:
- Static routing (IPv4/IPv6), 512 entries
- Dynamic routing: RIPv2, OSPFv2/v3
- 128 VLAN interfaces for routing
Layer 2 Features:
- VLAN: IEEE 802.1Q, Q-in-Q, MAC-, protocol- & voice-based
- Private VLAN, GVRP
- Link Aggregation: 8 groups, up to 16 ports each
- STP, RSTP, MSTP (up to 7 instances), Root Guard
- ERPS Ring Protocol (G.8032)
- IGMP/MLD Snooping, MVR
- UDLD support (Cisco compatible)
Quality of Service:
- 8 priority queues, WRR and Strict Priority
- QoS classification: 802.1p, DSCP, IP Precedence, TCP/UDP
- Ingress/Egress rate limiting
Security:
- IEEE 802.1X, MAC-based authentication
- RADIUS, TACACS+ support
- Access Control Lists: IP, MAC
- DHCP Snooping, ARP Inspection, IP Source Guard
- Port security & static MACs
Management & Monitoring:
- Management Interfaces: Web GUI, Console, Telnet, SNMP v1/v2c/v3
- Secure: SSHv2, TLSv1.2
- SNMP Traps, Syslog, SMTP Alerts
- Tools: PLANET UNI-NMS, Smart Discovery, CloudViewerPro
- Diagnostics: SFP-DDM, Remote Ping, Cable Test
- Dual firmware images
Hardware & Environment:
- Dimensions: 444 x 301 x 44 mm (1U)
- Weight: 4.285 kg
- Power Input: 100–240V AC, 50/60Hz
- Power Consumption: Up to 502W (full load)
- Operating Temp: 0–50 °C
- Storage Temp: -20–70 °C
- ESD Protection: 6KV
- Surge Protection: 4KV
- Cooling: 3 smart fans
