PLANET Industrial 8-Port Wall-mount Switch WGS-4215-8P2XV
|
471,40 EUR |
|
|
( 560,97 EUR incl. VAT ) ≈ £406.35 | ≈ $534.57 plus delivery charges: 53,00 € |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 739643 |
|---|---|
| Mfg Part No: | WGS-4215-8P2XV |
| UPC/EAN: | 4711605288248 |
| Weight: | 0.12 kg |
Product information for Planet WGS-4215-8P2XV:
The PLANET WGS-4215-8P2XV is an industrial-grade L2+/L3 managed switch equipped with 8 PoE+ Gigabit RJ45 ports, 2 10G SFP+ uplinks, and a built-in 2.4-inch LCD touchscreen for direct, user-friendly configuration and monitoring. Designed for wall-mount deployment in tight industrial spaces, this switch is ideal for smart building networks, video surveillance, wireless AP deployment, and secure high-bandwidth applications.
Key Features:
- 8x 10/100/1000BASE-T with IEEE 802.3at PoE+ (up to 36W/port)
- 2x 100/1G/2.5G/10GBASE-X SFP+ uplink slots
- 288W total PoE power budget (dual power input)
- Touchscreen control panel for intuitive on-site management
- L3 VLAN routing with up to 32 static IPv4/IPv6 routes
- Intelligent PoE features: PD alive check, PoE scheduling, timed reboot, 250m extended mode
- ERPS (G.8032) ring support, MSTP, <10ms recovery time
- Comprehensive cybersecurity: ACLs, 802.1X, RADIUS, ARP Inspection, TACACS+
- Modbus TCP support for SCADA integration
Technical Specifications:
Interfaces:
- 8x PoE+ Gigabit RJ45 ports
- 2x 100M/1G/2.5G/10G SFP+ fiber slots
- 1x 6,1 cm ( 2,4 inch ) color LCD touchscreen
Hardware & Mounting:
- Rugged IP30 metal enclosure
- Fixed wall-mount, magnetic or DIN-rail installable
- Dimensions: 245 × 36 × 140 mm; Weight: ~930g
- Operating temperature: -20 to 70°C
PoE Capabilities:
- 802.3af/at compliance, up to 36W/port
- Total PoE budget: 288W (with dual DC input)
- Extended mode: 250m @10Mbps
- Intelligent control: schedule, reboot, status monitoring, per-port power limit
Switch Performance:
- Switching capacity: 56 Gbps
- Throughput: 41.67 Mpps
- Jumbo frames: 12KB, 16K MAC table
Layer 2+ Switching:
- VLAN: 802.1Q, Q-in-Q, Voice, Private, GVRP
- Trunking: 8 groups, 8 ports each (LACP, static)
- Spanning Tree: STP, RSTP, MSTP + BPDU guard/filtering
- IGMPv2/v3 and MLDv1/v2 snooping (256 groups each)
Layer 3 Routing:
- Static routing (IPv4/IPv6), 32 routes max.
- VLAN interface routing (up to 64 interfaces)
Security & Access Control:
- ACLs: IPv4/IPv6 & MAC-based, 256 entries
- 802.1X (Port & MAC), RADIUS/TACACS+
- DHCP Snooping, IP Source Guard, ARP Inspection
- DoS protection, port security
Management:
- Web GUI, CLI via Telnet/SSH, SNMPv1/v2c/v3, TLS 1.2
- LCD Panel: IP, VLAN, QoS, PoE control, cable diagnostics, ping, factory reset
- Centralized management with PLANET NMS/CloudViewerPro
- Dual image firmware, syslog, SNTP, LLDP/LLDP-MED
Diagnostics & Monitoring:
- Real-time SFP-DDM (Tx/Rx power, temp, voltage)
- Remote ping (ICMPv4/v6), cable diagnostics
Questions & answers
What is the delivery time of PLANET Industrial 8-Port Wall-mount Switch WGS-4215-8P2XV?
The article PLANET Industrial 8-Port Wall-mount Switch WGS-4215-8P2XV is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 16 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Planet WGS-4215-8P2XV to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you PLANET Industrial 8-Port Wall-mount Switch WGS-4215-8P2XV always at the best possible price. We can give you a discount of 2% on PLANET Industrial 8-Port Wall-mount Switch WGS-4215-8P2XV if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
