PLANET Industrial 8-Port M12. 4pin 802.3at PoE+ switch
|
461,36 EUR |
|
|
( 549,02 EUR incl. VAT ) ≈ £397.69 | ≈ $523.18 plus delivery charges: 53,00 € |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 270437 |
|---|---|
| Mfg Part No: | ISW-808PT-M12 |
| UPC/EAN: | 4711605285049 |
| Weight: | 0.12 kg |
Product information for Planet ISW-808PT-M12:
Reliable Data and Power over Ethernet:
This switch supports up to 8 IEEE 802.3af/at PoE devices, offering a total PoE budget of 180 watts. It delivers 54V DC per port via robust M12 connectors, ensuring dependable operation even in high-vibration environments.
Perfect for Transportation and Vehicle Networks:
The ISW-808PT-M12 features built-in power boost technology, converting 12–54V DC input to 54V PoE output, making it ideal for vehicles and field deployments where power fluctuation is common.
Technical Specifications:
Physical Interfaces:
– 8 x 10/100BASE-TX M12 D-coded female connectors (PoE+ supported)
– 1 x M23 5-pin A-coded male power connector
Switching:
– Switching Fabric: 1.6 Gbps– Throughput: 1.19 Mpps @ 64 Bytes
– MAC Address Table: 2K entries
– Forwarding Method: Store-and-Forward
– Jumbo Frame: 1536 bytes
PoE Capabilities:
– Standards: IEEE 802.3at (PoE+), IEEE 802.3af– Output: 54V DC, up to 36W per port
– Budget: Up to 180W (48–56V input), 120W (24–48V), 60W (12–23V)
– Pin Assignment: 1/2(+), 3/6(–)
– Max Distance: 100 meters per port
Housing & Installation:
– IP67-rated aluminum housing
– Dimensions: 124 x 53.1 x 204 mm
– Weight: 1.75 kg
– Mounting: DIN-rail and wall-mount supported
Power Supply:
– Input: Dual 12–54V DC, redundant with reverse polarity protection– Power Consumption:
– 12V DC: 75.6W
– 24V DC: 129.3W
– 48V DC: 190.1W
– 54V DC: 191.7W
Protection & Compliance:
– ESD Protection: 6KV DC
– Surge Protection: 6KV DC
– Certifications: EN50155, FCC Part 15 Class A, CE
– Operating Temperature: -40 ~ 75 °C
– Humidity: 5–95% RH (non-condensing)
