PLANET Industrial 8-Port GE 802.3bt PoE++ IGS-6329-8UP2S4X
|
856,82 EUR |
|
|
( 1.019,62 EUR incl. VAT ) ≈ £738.58 | ≈ $971.63 plus delivery charges: 53,00 € |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 2024810 |
|---|---|
| Mfg Part No: | IGS-6329-8UP2S4X |
| UPC/EAN: | 4711605286398 |
| Weight: | 2.08 kg |
Product information for Planet IGS-6329-8UP2S4X:
The PLANET IGS-6329-8UP2S4X is an industrial-grade Layer 3 managed PoE++ switch engineered for rugged and electromagnetically harsh environments. With IP30 metal housing, EN 61000-6-2/6-4 EMC immunity, and EN 50121-4 railway certification, it ensures uninterrupted data transmission and reliable PoE injection even under heavy industrial interference.
Equipped with eight 10/100/1000BASE-T PoE++ ports (up to 95W each), two 100/1000/2500BASE-X SFP ports, and four 10GBASE-SR/LR SFP+ uplink ports, it supports PoH and non-standard 4-pair PoE PDs. Ideal for high-power devices such as PTZ cameras, touch panel PCs, PoE lighting, and signage displays.
With wide temperature tolerance from -40 to +75 °C, redundant power input, advanced Layer 2/3 capabilities, and intuitive management via Web GUI, CLI, or SNMP, the IGS-6329-8UP2S4X is perfect for mission-critical industrial, transportation, or data center applications.
Technical Details:
Ports:
- 8x 10/100/1000BASE-T PoE++ (up to 95W/port)
- 2x 100/1000/2500BASE-X SFP
- 4x 10GBASE-SR/LR SFP+ (1G/2.5G compatible)
- 1x RJ45-to-RS232 console port
PoE Capabilities:
- IEEE 802.3bt Type-4, PoH, Force Mode, Legacy
- Total PoE budget: up to 360W
- PoE management: scheduling, reboot, power priority, usage monitoring
Routing & Switching:
- Layer 3 routing: RIP, OSPF, static IPv4/IPv6
- Switching capacity: 106 Gbps, 78.87 Mpps
- VLAN: 4K groups, Q-in-Q, MAC/Protocol/Port-based
- Link aggregation: 4 groups, 4 ports each
- Ring protection: ERPS, STP/RSTP/MSTP
Industrial Specs:
- Operating temperature: -40 ~ 75 °C
- ESD protection: 6 kV (contact), 8 kV (air)
- Wall or DIN rail mounting
- IP30-rated aluminum housing
Alarms & Security:
- 2x DI, 2x DO for external alarms
- ACL, 802.1X, DHCP snooping, ARP inspection
Management:
- Web GUI, CLI, Telnet, SNMP v1/2c/3, SSHv2, TLS 1.2
- PLANET UNI-NMS & CloudViewer
- ONVIF support, topology map integration
Dimensions & Power:
- Size: 76 x 135 x 152 mm
- Weight: 1.62 kg
- Dual DC 48~54V, up to 430W consumption
