PLANET Industrial L3 20-Port IGS-6325-20T4C4X
|
875,32 EUR |
|
|
( 1.041,63 EUR incl. VAT ) ≈ £754.53 | ≈ $992.61 plus delivery charges: 53,00 € |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 309768 |
|---|---|
| Mfg Part No: | IGS-6325-20T4C4X |
| Weight: | 0.12 kg |
Product information for Planet IGS-6325-20T4C4X:
Industrial 24-Port Gigabit Switch with 10G Uplink and Advanced L3 Routing
The PLANET IGS-6325-20T4C4X is a 1U rackmount Layer 3 Managed Industrial Switch equipped with 24 10/100/1000BASE-T copper ports, 4 shared SFP ports, and 4 10GBASE-SR/LR SFP+ slots. With up to 128Gbps non-blocking switch fabric, it supports full wire-speed performance and robust VLAN routing. Its hardened design with -40 to 75 °C operation, dual AC/DC power input, and advanced routing makes it an ideal choice for industrial backbones, telecom infrastructures, and mission-critical automation environments.
Technical Specifications (English):
Interfaces:
- 24 x 10/100/1000BASE-T RJ45
- 4 x 100/1000BASE-X SFP (shared with ports 21–24)
- 4 x 10GBASE-SR/LR SFP+ (compatible with 1G/2.5G)
- 1 x Console (RJ45 to RS232 DB9)
Switching Capacity:
- Switch Fabric: 128Gbps / Throughput: 95.2 Mpps
- MAC Table: 16K
- Jumbo Frame: 10K bytes
- Architecture: Store-and-Forward
Layer 3 Routing:
- IPv4/IPv6 Static Routing (up to 128 entries)
- VLAN-based Routing Interfaces
- OSPFv2 Dynamic Routing
Layer 2 Features:
- VLAN: 802.1Q, Q-in-Q, Private VLAN, MAC/IP/Subnet/Protocol/Voice VLAN
- Link Aggregation: 14 groups, 16 ports per group (up to 32Gbps)
- Spanning Tree: STP, RSTP, MSTP, BPDU Guard
- Multicast: IGMP/MLD Snooping, MVR, Querier Mode
- QoS: 8 queues, DSCP, WRR, 802.1p, ToS
- Bandwidth Control: 100Kbps to 1Gbps per port
Security:
- ACL: IP/MAC-based (256 entries)
- 802.1X (Port/MAC), RADIUS/TACACS+
- DHCP Snooping, IP Source Guard, DAI
- Private VLAN for port isolation
Alarm & Monitoring:
- 2 DI / 2 DO alarm ports
- DDM for SFP diagnostics (temperature, optical power, etc.)
- LED indicators for system/port/alarm
- Remote alerts via SNMP/Syslog/Email
Management:
- Interfaces: Web GUI, Telnet, Console, SNMP v1/v2c/v3
- Secure Access: SSHv2, TLSv1.2
- Utilities: PLANET NMS, Smart Discovery, CloudViewer
- Protocols: LLDP, NTP, DHCP Server/Relay, TFTP
- Dual image firmware for failover
Industrial Design:
- IP30 metal housing, 1U rackmount
- Dual Power: AC 100–240V and DC 36–60V (redundant)
- Operating Temp: -40 to 75 °C (DC) / -10 to 60 °C (AC)
- ESD/EFT protection: 6KV
Package Contents:
- IGS-6325-20T4C4X
- Quick Installation Guide
- AC Power Cord
- RJ45 Dust Caps
- 19” Rackmount Kit
- RJ45 to RS232 Console Cable
