PLANET Industrial 16-Port Managed Switch IGS-4215-16T2S
|
365,19 EUR |
|
|
( 434,58 EUR incl. VAT ) plus delivery charges |
|
| Delivery time from supplier's stock (ca.) 1 workdaysinfo_outline | |
| In Stock: 1 pieces | |
| Lieske Part No.: | 2063872 |
|---|---|
| Mfg Part No: | IGS-4215-16T2S |
| UPC/EAN: | 4711605284899 |
| Weight: | 1.18 kg |
Product information for Planet IGS-4215-16T2S:
Cost-Effective Industrial Switch for Harsh Environments
The PLANET IGS-4215-16T2S / IGS-4215-16T2S-U is a DIN-rail type L2/L4 managed industrial Gigabit switch designed for demanding environments. It features 16 Gigabit RJ45 ports and 2 100/1000BASE-X SFP uplinks for long-distance fiber connectivity. With its robust IP30-rated case, extended -40 to 75 °C operating range, dual DC/AC power inputs, and advanced security and traffic control features, it ensures reliable performance for critical networks.
Key Features:
- 16 x Gigabit RJ45 ports, 2 x 100/1000BASE-X SFP slots
- Operates in -40 to 75 °C, fanless aluminum housing
- Redundant power input: DC 9~48 V or AC 24 V
- VLAN, LACP, MSTP, QoS, ACLs, DHCP Snooping, IGMP/MLD
- Web/CLI/SNMPv3 management, supports UNI-NMS & CloudViewer
Technical Specs (English):
Ports:
- 16 x 10/100/1000BASE-T RJ45 (Auto-MDI/MDI-X)
- 2 x 100/1000BASE-X SFP slots
- 1 x RJ45 console (IGS-4215-16T2S), 1 x Micro-USB console (IGS-4215-16T2S-U)
Switching Capacity:
- Store-and-Forward
- Switching Fabric: 36Gbps, Throughput: 26.79Mpps
- MAC Table: 8K entries, Jumbo Frame: 10K
Power Supply:
- IGS-4215-16T2S: 12~48V DC or 24V AC
- IGS-4215-16T2S-U: 9~48V DC or 24V AC
- Redundant inputs with failover protection
- Max power usage: 15W (full load)
Layer 2 Features:
- VLANs: 802.1Q, Q-in-Q, Private, Protocol, Voice VLAN, GVRP
- Spanning Tree: STP/RSTP/MSTP with BPDU Guard
- Link Aggregation: LACP, up to 8 groups of 8 ports (16Gbps trunks)
- IGMP/MLD Snooping (v1–v3), Querier, LLDP, ERPS (<450ms)
- Port Mirroring, Loop Protection, MAC/VLAN Table
QoS & Traffic Control:
- 8 queues per port, 802.1p/DSCP/TOS classification
- Ingress/Egress bandwidth shaping, DSCP remarking
Security Features:
- IEEE 802.1X with RADIUS/TACACS+ auth
- IPv4/IPv6 ACLs, Port Security, IP Source Guard
- DHCP Snooping, ARP Inspection, DoS protection
Management:
- Web GUI, Telnet/SSH, SNMPv1/v2c/v3, TLSv1.2
- Dual firmware images, SNMP traps, LLDP, NTP, RMON
- Remote diagnostics: Cable testing, ICMP ping, DDM
- PLANET UNI-NMS and CloudViewer ready
SFP Monitoring:
- SFP-DDM (Digital Diagnostics): output/input power, temperature, voltage
Mechanical & Environmental:
- IP30 metal housing, DIN-rail & wall-mount
- ESD Protection: ±6kV contact discharge
- Operating Temp: -40 to 75 °C, Humidity: 5–95%
- Dimensions: 66 x 107 x 152 mm, Weight: 813g / 829g
Questions & answers
What is the delivery time of PLANET Industrial 16-Port Managed Switch IGS-4215-16T2S?
The article PLANET Industrial 16-Port Managed Switch IGS-4215-16T2S is currently in stock
According to our experience the article is ready for dispatch within 1 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Planet IGS-4215-16T2S to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you PLANET Industrial 16-Port Managed Switch IGS-4215-16T2S always at the best possible price. We can give you a discount of 2% on PLANET Industrial 16-Port Managed Switch IGS-4215-16T2S if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
