PLANET 1Port RS232/422/485 to 1Port 100Base-FX SFP Converter
|
89,20 EUR |
|
|
( 106,15 EUR incl. VAT ) ≈ £76.89 | ≈ $101.15 plus delivery charges: 53,00 € |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 276392 |
|---|---|
| Mfg Part No: | ICS-115A |
| UPC/EAN: | 4711605285018 |
| Weight: | 0.44 kg |
Product information for Planet ICS-115A:
Equipped with comprehensive protocol support, remote management capabilities (Web, Telnet, VCOM), and compatibility with PLANET’s media converter chassis, the ICS-115A simplifies the modernization of serial-based infrastructures.
Technical Specifications (EN):
Serial Interface:
- 1x DB9 male (RS232, RS422, RS485 2-wire/4-wire)
- Baud Rate: 50 to 921600 bps
- Data Bits: 5, 6, 7, 8
- Stop Bits: 1, 1.5, 2
- Parity: None, Odd, Even, Space, Mark
- Flow Control: RTS/CTS, DTR/DSR (RS232 only), XON/XOFF
- Modes: VCOM, RFC2217, TCP Server/Client, UDP, Remote Pair, Modbus, Telnet
Ethernet Interface:
- 1x 100BASE-FX SFP slot (range varies from 2 km to 120 km depending on SFP)
- ESD Protection: 6KV
Management & Security:
- Web and Telnet console, Windows VCOM Utility
- PLANET Smart Discovery, SNMP v1/v2c, SNMP Trap, UNI-NMS
- Accessible IP security whitelist
- Alerts via Syslog and SNMP trap
- Dual stack IPv4/IPv6
- DHCP client, NTP, HTTP, Telnet, DHCPv6, ICMP, Modbus
Housing & Installation:
- Dimensions: 94 × 70.3 × 26.2 mm
- Weight: 185 g
- Material: Metal, IP30
- Mounting: Wall, DIN-rail, or PLANET media chassis (MC-700/1500)
- Reset Button: <5s for reboot, >5s for factory reset
- Power Input: 5V DC, 2A
- Power Consumption: max. 5.5 W
- Operating Temp: -10 to 60 °C
- Humidity: 5–95% (non-condensing)
