PLANET 24-Port 1000T 802.3at PoE + 2-Port Gigabit SFP (300W)
|
357,07 EUR |
|
|
( 424,91 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1226039 |
|---|---|
| Mfg Part No: | GSW-2620VHP |
| UPC/EAN: | 4711605282109 |
| Weight: | 4.4 kg |
Product information for Planet GSW-2620VHP:
Key Features:
- 24x 10/100/1000BASE-T RJ45 ports with 802.3af/at PoE+
- 2x 1000BASE-X SFP slots for long-distance fiber uplinks
- Total PoE Power Budget: 300 watts
- Up to 30 watts per port
- Real-time PD Alive Check and port management
Smart LCD Management & Modes:
- Standard Mode: Full bandwidth and power on all ports
- VLAN Mode: Port-based isolation to prevent broadcast/multicast storm
- Extend Mode: 10Mbps transmission with PoE up to 250 meters and 20W power output
- LCD Display shows per-port PoE usage, priorities, status, budget alerts, and maintenance options
Networking Capabilities:
- Switching Capacity: 52 Gbps, Throughput: 38.7 Mpps
- 8K MAC address table
- Jumbo frame support up to 9216 bytes
- IEEE 802.3x for full-duplex flow control and backpressure for half-duplex
- Store-and-Forward switching with auto MDI/MDI-X detection
PoE Details:
- Standards: IEEE 802.3af/at compliant
- End-span pinout: 1/2 (+), 3/6 (–)
- Circuit protection to avoid damage from power surges or loops
- Remote PoE transmission up to 100m (standard), 250m (extend)
Build & Protection:
- Metal enclosure, 1U rack-mountable, dimensions: 440.5 x 231.08 x 44.5 mm
- Weight: 3.5 kg
- 3 silent fans for temperature control
- ESD Protection: ±6KV contact, ±8KV air; Surge Immunity: ±6KV
Ideal Applications:
- Centralized PoE management for up to 24 IP cameras in surveillance networks
- Enterprise VoIP systems and wireless AP networks
- Long-distance network extension using SFP fiber uplinks
Environmental Conditions:
- Operating Temperature: -10 ~ 60 °C
- Storage Temperature: -10 ~ 70 °C
- Relative Humidity: 10 ~ 90% (non-condensing)
Questions & answers
What is the delivery time of PLANET 24-Port 1000T 802.3at PoE + 2-Port Gigabit SFP (300W)?
The article PLANET 24-Port 1000T 802.3at PoE + 2-Port Gigabit SFP (300W) is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 16 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Planet GSW-2620VHP to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you PLANET 24-Port 1000T 802.3at PoE + 2-Port Gigabit SFP (300W) always at the best possible price. We can give you a discount of 2% on PLANET 24-Port 1000T 802.3at PoE + 2-Port Gigabit SFP (300W) if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
