PLANET 8-Port 10/100/1000T + 2-Port 100/1000X SFP

The PLANET GS-4210-8T2S is a high-performance 8-Port Managed Gigabit Switch with two additional SFP fiber interfaces, tailored for edge and backbone deployments in business networks. With fanless, silent operation and 20 Gbps switch fabric, it is an excellent choice for SOHOs and SMBs looking to expand or optimize their network performance and security.

It delivers robust L2/L4 features including VLANs, ERPS, link aggregation, IGMP snooping, and advanced QoS. Equipped with strong cybersecurity protocols like 802.1x authentication, ACLs, and SNMPv3, it ensures reliable and secure data transmission, especially across fiber optic uplinks with integrated SFP diagnostics.

Technical Specifications:

Interfaces:

• 8 x 10/100/1000BASE-T RJ45 copper ports
• 2 x 100/1000BASE-X SFP slots (auto-detect)
• 1 x RS232 RJ45 console port

Switching & Performance:

• Architecture: Store-and-Forward
• Switch Fabric: 20 Gbps (non-blocking)
• Throughput: 14.88 Mpps
• Jumbo Frame: 10K bytes
• MAC Address Table: 8K entries
• Shared Buffer: 4.1 Mbit

Layer 2 Features:

• VLAN support: 802.1Q, Q-in-Q, Voice VLAN, Private VLAN, Management VLAN, GVRP
• VLAN Groups: up to 256
• Link Aggregation: LACP/static, 1 group with 2 ports
• Spanning Tree: STP, RSTP, MSTP with BPDU Guard/Filtering
• ERPS (Ethernet Ring Protection Switching)
• IGMP snooping (v2/v3), IGMP Querier
• MLD snooping (v1/v2)
• LLDP & LLDP-MED
• Port Mirroring, Loop Protection

QoS & Traffic Management:

• 8 levels of traffic prioritization
• Classification: 802.1p, VLAN tag, DSCP/IP precedence
• Scheduling: Strict priority and WRR
• Bandwidth Control: Per-port ingress/egress limits
• Storm Control: Broadcast/Unicast/Multicast suppression

Security:

• Authentication: 802.1X (port-based), RADIUS, TACACS+
• ACL: IPv4/IPv6 and MAC-based
• MAC Security: Filtering, static MACs, port protection
• IP Protection: DHCP snooping, ARP inspection, IP Source Guard, DoS prevention

Management:

• IPv6/IPv4 dual stack support
• Interfaces: Web GUI, Telnet, CLI, SNMP v1/v2c/v3
• Secure Access: SSHv2, TLSv1.2
• Features: TFTP client, Syslog, SNTP, dual firmware images
• Diagnostics: Cable testing, SFP-DDM (real-time optics monitoring)
• Monitoring: RMON (4 groups), event logging
• Tools: PLANET Smart Discovery Utility, PLANET NMS system

Mechanical & Power:

• Enclosure: Metal, compact and fanless
• Dimensions: 280 x 180 x 44 mm
• Weight: 1315g
• Power Input: AC 100–240V, 2.5A
• Max Consumption: 6.8W / 23.2 BTU
• ESD Protection: 6kV contact / 8kV air
• Environment:
• Operating Temp: 0–50°C, 5–95% RH
• Storage Temp: -20–70°C, 5–95% RH
