PLANET 16-Port Layer 2 Managed Gigabit Ethernet Switch +
|
164,78 EUR |
|
|
( 196,09 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1225915 |
|---|---|
| Mfg Part No: | GS-4210-16T2S |
| Weight: | 3.18 kg |
Product information for Planet GS-4210-16T2S:
Equipped with comprehensive Layer 2/4 capabilities—including VLANs, QoS, link aggregation, IGMP/MLD snooping, and extensive ACL support—the switch ensures optimal traffic management and high-level security. Dual-stack IPv6/IPv4 support allows future-proofed network deployments, and secure remote access is guaranteed through SSHv2, TLS v1.2, and SNMPv3.
With ITU-T G.8032 ERPS ring support and uplink extension options via SFP fiber modules (up to 120km), the GS-4210-16T2S is perfect for edge, server farm, and FTTx/MAN applications.
Technical Specifications:
Ports:
- 16x 10/100/1000BASE-T RJ45
- 2x 100/1000BASE-X SFP slots
- 1x RS232-to-RJ45 Console
- Reset Button: <5s reboot / >5s factory reset
Switching:
- Switching Fabric: 36 Gbps / 26.7 Mpps
- MAC Table: 8K entries
- Jumbo Frame: 9216 bytes
- Shared Buffer: 4.1 Mbit
- Flow Control: IEEE 802.3x (full duplex), back pressure (half duplex)
- Store-and-Forward architecture
Layer 2 Features:
- VLAN: IEEE 802.1Q, Q-in-Q, Voice, Protocol, Private, Management, GVRP
- Spanning Tree: STP, RSTP, MSTP with BPDU Guard/Filter
- Link Aggregation: 8 groups, 8 ports/group, LACP and Static
- Port Mirroring (many-to-1), Loop Protection
- ERPS (ITU-T G.8032) support
QoS & Traffic Management:
- 8 Priority Queues with WRR and Strict Priority
- Classification by Port, 802.1p, DSCP, IP Precedence
- Ingress/Egress bandwidth control per port
- Storm Control: broadcast, unknown unicast, unknown multicast
Multicast:
- IPv4 IGMP Snooping v2/v3, Querier, up to 256 groups
- IPv6 MLD Snooping v1/v2, up to 256 groups
Security Features:
- Authentication: 802.1X (port-based), RADIUS, TACACS+
- DHCP Option 82, IP Source Guard, Dynamic ARP Inspection, DoS protection
- MAC Security: static MAC, filtering, IP-MAC binding
- ACLs: IPv4/IPv6 and MAC-based
- Port Security: MAC device count limitation
Management:
- IPv4/IPv6 Dual Stack
- Interfaces: Web GUI, Telnet CLI, Console
- SNMP v1, v2c, v3 (encrypted)
- Secure Access: SSHv2, TLS v1.2
- Maintenance: firmware/config via HTTP/TFTP, dual image
- Time Sync: SNTP, LLDP/LLDP-MED
- Logs: Syslog, SNMP traps, RMON (1,2,3,9)
- Tools: PLANET Smart Discovery, NMS, CloudViewer
Hardware & Power:
- Dimensions: 441.2 x 207.5 x 44 mm (1U)
- Weight: 2 kg
- Enclosure: Metal
- Power: 100–240V AC, max. 10.4W / 35 BTU
- Fan: Fanless (silent operation)
Certifications & Environment:
- Regulatory: FCC Part 15 Class A, CE
- Operating Temp: 0–50 °C
- Storage Temp: -10–70 °C
- Humidity: 5–95% (non-condensing)
Questions & answers
What is the delivery time of PLANET 16-Port Layer 2 Managed Gigabit Ethernet Switch +?
The article PLANET 16-Port Layer 2 Managed Gigabit Ethernet Switch + is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 16 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Planet GS-4210-16T2S to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you PLANET 16-Port Layer 2 Managed Gigabit Ethernet Switch + always at the best possible price. We can give you a discount of 2% on PLANET 16-Port Layer 2 Managed Gigabit Ethernet Switch + if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
