PLANET 5-Port 10/100Mbps Fast Ethernet Switch, Metal
|
22,33 EUR |
|
|
( 26,57 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1226548 |
|---|---|
| Mfg Part No: | FSD-503 |
| UPC/EAN: | 4711213680304 |
| Weight: | 0.12 kg |
Product information for Planet FSD-503:
The PLANET FSD-503 is a compact, energy-efficient Fast Ethernet switch designed for small office, home office (SOHO), and home networking environments. It delivers excellent performance in a space-saving design, with power consumption reduced by 28% compared to its predecessor.
Compact and Flexible Installation:
With dimensions of just 100 x 64 x 24 mm and a weight of only 148g, the FSD-503 fits easily into tight networking spaces. The desktop or wall-mountable design makes it ideal for SOHO applications.High-Speed Ethernet Switching:
Equipped with five 10/100Mbps ports, the FSD-503 utilizes a Store-and-Forward switching mechanism for low-latency and high-integrity data delivery. It offers excellent throughput with wire-speed packet forwarding rates up to 148,800pps at 100Mbps, ideal for workgroups of up to 50 users.Plug & Play Simplicity:
All RJ45 ports support 10/100Mbps auto-negotiation and auto-MDI/MDI-X, allowing easy connection without crossover cables. IEEE 802.3x flow control ensures reliable performance in full-duplex mode, making it easy to connect directly to routers, servers, or other switches.
Smart MAC Address Management:
The FSD-503 supports up to 1,000 MAC addresses and uses a 488Kbit packet buffer for optimized bandwidth. Its intelligent address learning and aging features provide seamless packet forwarding without loss.Technical Specifications (English):
Ports:
- 5 x 10/100BASE-TX RJ45 ports, Auto MDI/MDI-X
Switching:
- Store-and-Forward processing
- MAC address table: 1K entries
- Shared data buffer: 488Kbits
- Switch fabric: 1Gbps
- Throughput: 0.744Mpps
- Max packet size: 1536 bytes
Hardware:
- Metal enclosure, desktop or wall-mountable
- LEDs: Power, Link/Act per port
- Power adapter: 5V DC, 550mA
- Power consumption: 1.3W / 4.4BTU
Standards Compliance:
- IEEE 802.3 (Ethernet)
- IEEE 802.3u (Fast Ethernet)
- IEEE 802.3x (Flow Control)
- IEEE 802.3az (Energy Efficient Ethernet)
- FCC Part 15 Class B, CE
Environment:
- Operating temperature: 0–50°C
- Storage temperature: -10–70°C
- Humidity: 5–95% (non-condensing)
Questions & answers
What is the delivery time of PLANET 5-Port 10/100Mbps Fast Ethernet Switch, Metal?
The article PLANET 5-Port 10/100Mbps Fast Ethernet Switch, Metal is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 16 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Planet FSD-503 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you PLANET 5-Port 10/100Mbps Fast Ethernet Switch, Metal always at the best possible price. We can give you a discount of 2% on PLANET 5-Port 10/100Mbps Fast Ethernet Switch, Metal if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
