Niedax KKL80.200 cable tray GRP 80x200x3000mm molded connector gel. content_copy

GRP cable tray, pressed, with unperforated side rails, with molded connector, with transverse reinforcements (5 mm) over the entire width of the cable tray and seven rows of fastening holes in the base, mechanical strength in accordance with IEC 61537, please order corresponding fastening accessories separately, halogen-free. Due to the transverse reinforcements, the cable tray is also approved for use with high-frequency cables in accordance with UTE C15-900 (application class D, frequency 16 MHz). An expansion distance of 8 mm must be taken into account. Due to the expansion of the material, the following must be observed during assembly: - The cable tray should not be screwed close to or at the joint. - When screwing the cable tray onto the brackets, a through hole of Ø 9 mm for the FKM 6X20 E4 screws must always be made in the tray. Article also available in ...AC (resin mixture with acrylic resin). Dimensions (approx. dimensions) H x W : 80 x 200 mm Material thickness t : 3 mm Bottom bead shape : 60 x 5 mm Bottom bead shape Grid dimension : 313 mm Bottom perforation : 9 x 20 mm Row spacing : 25 mm Bottom hole spacing Grid dimension : 313 mm Load capacity F at a support spacing of 1.5 m : 0.5 kN/m Delivery length : 3000 mm Usable cross-section : 13320 mm² Material : UP-GF (glass fiber reinforced polyester) Color : pebble gray RAL : 7032 (similar)
Type: KKL 80.200

The item price shown refers to 3 meters Niedax KKL80.200
