Microsens 45x45 cable duct installation kit cavity wall incl. cup, MS140040HW3

45x45 cavity wall installation set incl. cup, equipment tray, cover frame, blind cover, pure white
The four-part cavity wall installation set is designed directly for modular technology 45 and offers enough space for MICROSENS installation components. For better accessibility to both power and fiber optic connections, this set is designed with a 3-fold 45mm frame. A blind cover is included in the scope of delivery.
Optionally, a locking bracket can be installed to secure the micro switch. Hollow wall device box, 3-fold, support plate, cover frame and blind cover, pure white. Dimensions of the device box: 183 x 69 x 50The Accessories for MICROSENS Installation Components provide a comprehensive range of mounting and installation solutions for integrating fiber-optic-based network infrastructures in various environments. MICROSENS is a leading provider of Fiber-To-The-Office (FTTO) systems and offers a broad portfolio of accessories specifically designed to ensure optimal results during the installation of network components. The goal is to enable mechanically stable, standard-compliant, and aesthetically pleasing installations in different scenarios.

This guide serves as a reference for identifying the right accessories for specific installation situations, such as integration into device installation ducts, underfloor systems, or wall and desk installations. Additionally, the accessories support PoE+ components, modular enclosures, and industrial applications.

Key Features and Highlights:

• Wide Range of Solutions: Covers device installation channels, underfloor systems, wall installations, furniture mounting, and industrial environments.
• Modularity: Compatibility with M45 module technology for flexible and universal adaptations.
• PoE+ Support: Optimized mounting kits for PoE+ power supplies in various applications.
• Industrial Applications: IP67 mast boxes, DIN rail mounting, and 48,3 cm ( 19 inch ) adapters for industrial requirements.

Objective:

• Expand existing installations and enable new installations.
• Identify suitable accessory components for specific installation scenarios.
• Ensure mechanical stability, standard-compliant installations, and attractive design.

Application Areas and Accessory Details:

1. Device Installation and Channels:
- Mounting kits for various channels (e.g., Hager, Kleinhuis, Rehau).
- Support for E2 device boxes and front-mounted installations.
- Mounting solutions for PoE+ power supplies in installation channels.

2. Underfloor Installations:

- Compatibility with OBO underfloor systems, PUK underfloor systems, and electraplan supply units.
- Mounting kits for increased PoE+ demands.

3. Modular Enclosures:

- M45 enclosures for universal adaptations.
- Panels, cabling, and mounting kits for surface-mounted solutions.

4. Wall Installations:

- Solutions for hollow-wall, flush-mounted, and surface-mounted installations.
- Specific mounting kits for KAISER device boxes and PoE+ components.

5. Furniture Installations:

- Furniture recessed enclosures and retractable modular desk columns.

6. Industrial Installations:

- DIN rail mounting, IP67 mast boxes, and 48,3 cm ( 19 inch ) adapter solutions.
- Additional industrial accessories like cable routing, device connections, and locking blocks.

Summary:

With this extensive accessory range, MICROSENS offers solutions that meet technical requirements while also providing practical and aesthetic advantages. The compatible and modular components simplify the installation and maintenance of networks while enhancing system stability and reliability.

Compatibility:

• Fully compatible with MICROSENS FTTO network components and modular installation systems.
• Fits standard device boxes and installation systems from leading manufacturers (e.g., Hager, OBO BETTERMANN, PUK).

Special Features:

• Focus on easy installation and integration.
• Developed and manufactured to the highest quality standards (Made in Germany).

The accessory manual is an essential resource for planners, installers, and network administrators aiming for optimal results in FTTO installation.
