MICROSENS Mini-GBIC, 1000Mbit, LX / LC, MS100211
|
133,16 EUR |
|||||||||||
|
( 158,46 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 141312 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | MS100211 | ||||||||||
| Weight: | 0.01 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for MICROSENS MS100211:
The module complies with MSA and SFF-8472 standards, ensuring high compatibility and seamless integration into existing network infrastructures. The optional digital diagnostic function (DDM, model MS100001D) offers additional monitoring and management capabilities, allowing for optimized network performance and early problem detection.
Thanks to its hot-swappable design, the transceiver can be replaced during operation without interrupting network traffic. This saves time and minimizes downtime in mission-critical applications.
Technical Specifications:
Transceiver Types:
- MS100001
- MS100001D
Connector:
- LC plug (duplex)
Interface:
- Multimode
Range:
- Up to 2 km
Operating Temperature:
- 0 °C to +70 °C
Bandwidth:
- 1.0625 Gbps to 1.25 Gbps
Wavelength Range:
- TX: 1270–1355 nm
- RX: 1260–1610 nm
Power Budget:
- 10 dB
Transmit (Power):
- MIN/MAX: -9 / -1 dBm
Receiver (Sensitivity):
- MIN/MAX (overload): -19 / -1 dBm
Extinction Ratio:
- 9 dB
Laser Type:
- FP Laser
Protocol Support:
- Gigabit Ethernet
- Gigabit Fibre Channel
Features:
- Hot-swappable
- Optional digital diagnostic interface (DDM) with model MS100001D
- Compliant with MSA and SFF-8472 standards
- Laser Class 1 safety certification
Safety Notes:
- Never look directly into optical ports, as visible and invisible laser light can cause eye damage.
- Always cover unused ports with protective caps.
- Ensure all connections are fully established before activating the transmission line.
Ordering Information:
Questions & answers
What is the delivery time of MICROSENS Mini-GBIC, 1000Mbit, LX / LC, MS100211?
The article MICROSENS Mini-GBIC, 1000Mbit, LX / LC, MS100211 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 11 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of MICROSENS MS100211 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you MICROSENS Mini-GBIC, 1000Mbit, LX / LC, MS100211 always at the best possible price. We can give you a discount of 2% on MICROSENS Mini-GBIC, 1000Mbit, LX / LC, MS100211 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 5 pieces of MICROSENS Mini-GBIC, 1000Mbit, LX / LC, MS100211 we can offer you a price of 131,16 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
