LevelOne WAP-8231 AX1800 Wireless DualBand WiFi6 ws
|
81,93 EUR |
|
|
( 97,50 EUR incl. VAT ) ≈ £68.99 | ≈ $92.01 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: >50 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 2120721 |
| Mfg Part No: | WAP-8231 |
| UPC/EAN: | 4015867235690 |
| Weight: | 0.212 kg |
Further Access Points from LevelOneFurther products in category Access Points
All products of LevelOne
| Antenna | |
| Antenna type | Internal |
| Antennas quantity | 4 |
| Antenna gain level (max) | 3 dBi |
| Certificates | |
| Compliance certificates | CE, RoHS, UKCA |
| Design | |
| Placement | In-wall |
| Product colour | White |
| LED indicators | Wi-Fi |
| Features | |
| Maximum data transfer rate | 1800 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1201 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.412 -2.484, 5.18 - 5.825 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u |
| Cabling technology | 10/100/1000Base-T(X) |
| Channels quantity | 165 channels |
| MIMO type | Multi User MIMO |
| Spread spectrum method | OFDMA |
| Operating modes | AP Mode |
| 2.4 GHz | |
| 5 GHz | |
| 6 GHz | |
| MIMO | |
| Logistics data | |
| Country of origin | China |
| Master (outer) case width | 515 mm |
| Master (outer) case length | 348 mm |
| Master (outer) case height | 580 mm |
| Master (outer) case gross weight | 25 kg |
| Products per master (outer) case | 100 pc(s) |
| Management features | |
| Web-based management | |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 10 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Packaging content | |
| Interface adapter included | USB Type-C male - RJ-45 female |
| Mounting kit | |
| Quick start guide | |
| Packaging data | |
| Package width | 120 mm |
| Package depth | 110 mm |
| Package height | 65 mm |
| Package weight | 240 g |
| Package type | Box |
| Performance | |
| Flash memory | 16 MB |
| Internal memory | 128 MB |
| Ports & interfaces | |
| USB connector type | USB Type-C |
| WAN connection | Ethernet (RJ-45) |
| Power | |
| Power consumption (typical) | 14 W |
| Power over Ethernet (PoE) | |
| Security | |
| Security algorithms | WPA2-AES, WPA3 |
| Number of SSID supported | 8 |
| Sustainability | |
| Sustainability compliance | |
| Technical details | |
| Master (outer) cases per pallet (air) | 10 pc(s) |
| Pallet gross length | 80 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 189 cm |
| Weight & dimensions | |
| Width | 87 mm |
| Depth | 86 mm |
| Height | 31.5 mm |
| Weight | 138 g |
Questions & answers
What is the delivery time of LevelOne WAP-8231 AX1800 Wireless DualBand WiFi6 ws?
The article LevelOne WAP-8231 AX1800 Wireless DualBand WiFi6 ws is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of LevelOne WAP-8231 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you LevelOne WAP-8231 AX1800 Wireless DualBand WiFi6 ws always at the best possible price. We can give you a discount of 2% on LevelOne WAP-8231 AX1800 Wireless DualBand WiFi6 ws if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
