LevelOne GSW-1657 - switch - 16 ports - desktop
|
109,10 EUR |
|
|
( 129,83 EUR incl. VAT ) ≈ £91.86 | ≈ $122.52 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: >500 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 311504 |
| Mfg Part No: | GSW-1657 |
| UPC/EAN: | 4015867143117 |
| Weight: | 2.6 kg |
Further up to 16 ports from LevelOneFurther products in category up to 16 ports
All products of LevelOne
Product information for LevelOne GSW-1657:
Device Type: Switch - 16 ports Enclosure Type: Desktop - 1U Ports: 16 x 10/100/1000 MAC Address Table Size: 8000 entries Features: Flow control, auto-negotiation, auto-uplink (auto MDI / MDI-X ), store and forward, Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, Status Indicators: Link activity, port transmission speed, power, Interfaces: 16 x 10Base-T/100Base-TX/1000Base- T - RJ-45 Power Device: Power supply - internal Voltage Required: AC 120/230 V (50 - 60 Hz), width: 44 cm, depth: 18 cm, height: 4.4 cm, Rack Mounting Kit: Included, Compliant Standards: Plug and Play, FCC Class A certified, Min Operating Temperature: 0 ° C Max Operating temperature: 40 ° C
| Certificates | |
| Certification | FCC, CE |
| Data transmission | |
| Switching capacity | 32 Gbit/s |
| MAC address table | 8192 entries |
| Jumbo frames | 10000 |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Packet forwarding rate (100 Mbps) | 148000 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet buffer memory | 0.5 MB |
| Store-and-forward | |
| Jumbo frames support | |
| Design | |
| Product colour | Black, Grey |
| LED indicators | Activity, Link |
| Rack mounting | |
| Logistics data | |
| Master (outer) case width | 405 mm |
| Master (outer) case length | 500 mm |
| Master (outer) case height | 240 mm |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case gross weight | 11.8 kg |
| Management features | |
| Switch type | Unmanaged |
| Quality of Service (QoS) support | |
| Network | |
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable types supported | Cat5, Cat6, Cat7 |
| 10G support | |
| Full duplex | |
| Flow control support | |
| Auto MDI/MDI-X | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Packaging content | |
| Cables included | AC |
| Quick start guide | |
| Packaging data | |
| Package width | 224 mm |
| Package depth | 486 mm |
| Package height | 77 mm |
| Package weight | 2.15 kg |
| Mounting brackets included | |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 0.6 A |
| Power consumption (typical) | 13.3 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Weight & dimensions | |
| Width | 140 mm |
| Depth | 440 mm |
| Height | 44 mm |
| Weight | 1.48 kg |
Questions & answers
What is the delivery time of LevelOne GSW-1657 - switch - 16 ports - desktop?
The article LevelOne GSW-1657 - switch - 16 ports - desktop is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of LevelOne GSW-1657 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you LevelOne GSW-1657 - switch - 16 ports - desktop always at the best possible price. We can give you a discount of 2% on LevelOne GSW-1657 - switch - 16 ports - desktop if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
