LevelOne 1Port Extender Kit, 20km
|
232,23 EUR |
|
|
( 276,35 EUR incl. VAT ) ≈ £195.54 | ≈ $260.79 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: 2 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1390740 |
| Mfg Part No: | AVF-1101 |
| UPC/EAN: | 4015867206690 |
| Weight: | 0.46 kg |
| Features | |
| Type | AV transmitter |
| Maximum transfer distance | 20000 m |
| Fiber optic wavelengths supported | 1470-1610,1310 nm |
| Bandwidth | 6.5 MHz |
| RX sensitivity | -26 dB |
| Impedance | 75 Ω |
| Signal-to-Noise Ratio (SNR) | 60 dB |
| Linearity | 1.3%DG, 1.3°DP |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^9 bits read |
| Product colour | Black |
| Certification | CE, FCC |
| LED indicators | |
| Plug and Play | |
| Logistics data | |
| Master (outer) case gross weight | 11.5 kg |
| Products per master (outer) case | 17 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Packaging content | |
| AC adapter included | |
| Quick start guide | |
| Packaging data | |
| Package width | 185 mm |
| Package depth | 62 mm |
| Package height | 275 mm |
| Package weight | 600 g |
| Package type | Box |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Fiber optic connector | FC |
| BNC input ports | 1 |
| Power | |
| Operating voltage | 5 V |
| Input current | 3 A |
| Power consumption (typical) | 12 W |
| Technical details | |
| Country of origin | China |
| Weight & dimensions | |
| Width | 70 mm |
| Depth | 25 mm |
| Height | 90 mm |
| Weight | 460 g |
