INTELLINET 561259 16-Port Gigabit Ethernet PoE+ Switch 2 SFP Ports LCD Screen LCD Display PoE+/PoE 370W Endspan 19inch Rackmount
|
289,41 EUR |
|
|
( 344,40 EUR incl. VAT ) ≈ £243.68 | ≈ $325.01 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: 5 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1249411 |
| Mfg Part No: | 561259 |
| UPC/EAN: | 0766623561259 |
| Weight: | 3.859 kg |
| Certificates | |
| Certification | FCC A, CE, RoHS |
| Data transmission | |
| Switching capacity | 36 Gbit/s |
| MAC address table | 8192 entries |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Packet forwarding rate (100 Mbps) | 148800 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet buffer memory | 0.5 MB |
| Store-and-forward | |
| Design | |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Activity, Link, PoE, Power, Speed |
| Number of fans | 2 fan(s) |
| Rack mounting | |
| Stackable | |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Management features | |
| Switch type | Unmanaged |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 100BASE-TX, 1000BASE-T |
| Cable types supported | Cat5, Cat5e |
| 10G support | |
| Full duplex | |
| Flow control support | |
| Auto MDI/MDI-X | |
| Auto-sensing | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Packaging content | |
| Cables included | AC |
| Manual | |
| Rack mount kit | |
| Performance | |
| Noise level | 21.3 dB |
| Mean time between failures (MTBF) | 144000 h |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 420 W |
| Power protection features | Over voltage, Overload, Short circuit |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 370 W |
| Power over Ethernet (PoE) | |
| Weight & dimensions | |
| Width | 441.1 mm |
| Depth | 204.3 mm |
| Height | 44 mm |
| Weight | 4 kg |
Questions & answers
What is the delivery time of INTELLINET 561259 16-Port Gigabit Ethernet PoE+ Switch 2 SFP Ports LCD Screen LCD Display PoE+/PoE 370W Endspan 19inch Rackmount?
The article INTELLINET 561259 16-Port Gigabit Ethernet PoE+ Switch 2 SFP Ports LCD Screen LCD Display PoE+/PoE 370W Endspan 19inch Rackmount is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Intellinet 561259 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you INTELLINET 561259 16-Port Gigabit Ethernet PoE+ Switch 2 SFP Ports LCD Screen LCD Display PoE+/PoE 370W Endspan 19inch Rackmount always at the best possible price. We can give you a discount of 2% on INTELLINET 561259 16-Port Gigabit Ethernet PoE+ Switch 2 SFP Ports LCD Screen LCD Display PoE+/PoE 370W Endspan 19inch Rackmount if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
