Intellinet 523318 8 Ports Ethernet Switch - 8 x Network (RJ-45) Ports - 10/100Base-TX - 8 x Network
|
-7% 19,45 EUR 20,96 EUR |
|||||||||||
|
( 23,15 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time from supplier's stock (ca.) 7 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 110927 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 523318 | ||||||||||
| UPC/EAN: | 766623523318 | ||||||||||
| Weight: | 0.88 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for INTELLINET 523318:
The INTELLINET NETWORK SOLUTIONS 8-Port Fast Ethernet Office Switch is perfect for small and medium office environments, where searching for a stable, reliable and easy to deploy solution. The metal case is more robust than plastic and can also be used in environments such as warehouses, factories, etc..
Many-sided
The switch connects up to eight computers, servers, printers, switches and other devices with Ethernet cables with 10 or 100Mbps and works with any operating system
Easy installation and maintenance
The installation is plug and play. You need to perform any configuration and you do not need to deal with special cables for uplink port because each port is equipped with Auto MDI / MDI-X crossover. - Eight 10/100 Mbit / s ports with auto-sensing
- Supports any combination of 10 Mbit / s or 100 Mbit / s network devices
- The power-saving Green Ethernet technology off unused ports, and adjusts the power level according to the cable length to
- Auto MDI / MDI-X support on all ports
- Nway auto-negotiation on all ports
- Store and forward switching architecture
- Full / half duplex
- IEEE 802.3x flow control for full duplex
- No packet loss with half-duplex
- Packet filter rate: 148,800 pps (100 Mbps), 14,880 pps (10 Mbps)
- Supports 1024 MAC address entries
- 96 kBytes buffer memory
- LEDs for Power, Link / Activity, Full-and half-duplex
- Compact metal housing
- 3 years warranty standards
- IEEE 802.3 (10Base-T Ethernet)
- IEEE 802.3u (100Base-TX Fast Ethernet)
- IEEE 802.3x (flow control, for full duplex mode)
Generally
- Supported Media:
- 10Base-T Cat3, 4, 5 UTP / STP RJ-45 cable
- 100Base-TX Cat5 UTP / STP RJ-45 cable
- Packet filter / forwarding rate:
- 148,800 pps (100 Mbps)
- 14,880 pps (10 Mbps)
- Cache: 96 kbytes
- MAC Address Table Size: 1024 entries
- Switch architecture: store and forward
- Certified: FCC Class B, CE Mark
LEDs
- Power
- LINK / TX
- Voll-/Halb-Duplex
Current
- External power supply, 5 V, 600 mA
Technical Details
- Metal housing
- Dimensions: 85 (L) x 155 (W) x 25 (H) mm
- Weight: 420 g
- Operating temperature: 0 ° - 40 ° C
- Humidity: 10% - 90% RH, non-condensing
- Storage temperature: -20 ° - 70 ° C
Scope of delivery
- 8-Port Fast Ethernet Office Switch
- Power supply
- Manual Color: Black Product dimensions: 155 (W) x 85 (L) x 25 (H) mm
