InLine® VGA switch manual 2-port, 15-pin Sub-D HD
|
5,56 EUR |
|||||||||||
|
( 6,62 EUR incl. VAT ) ≈ £4.65 | ≈ $6.22 plus delivery charges: 55,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |||||||||||
| In Stock: >100 pieces | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 22195575 | ||||||||||
| Mfg Part No: | 60608 | ||||||||||
| UPC/EAN: | 4043718013968 | ||||||||||
| Weight: | 0.233 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Inline 60608:
No power supply required: Operates without additional power.
Clean video output: Supports resolutions up to 1920x1440.
Reliable connection: 1:1 pin assignment and shielded design.
Durable in use: Metal housing for robust handling.
The manual 2-way switch for VGA allows easy sharing and switching of 15-pin Sub-D signals between one computer and two monitors or two sources to one display. The mechanical switching operates independently of software and operating system. Thanks to 1:1 pin assignment and wired shielding, the signal path remains continuous and resolutions up to 1920x1440 are supported.
It is suitable for temporary workstation changes, presentation and meeting rooms as well as test setups in professional IT environments. It also allows existing infrastructure to be used and flexibly expanded without rewiring during on-site setups and service deployments.
Connection: 3x Sub-D HD 15-pin (female)
Switching: manual, mechanical
Direction: 1 input - 2 outputs or 2 inputs - 1 output
Resolution: up to 1920x1440
Pin assignment: 1:1
Shielding: shielded
Housing: metal housing
Power supply: not required
| Features | |
| Product colour | Black |
| Maximum resolution | 1920 x 1440 pixels |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package width | 950 mm |
| Package depth | 150 mm |
| Package height | 28 mm |
| Package weight | 233 g |
| Package volume | 4000 cm³ |
| Ports & interfaces | |
| Video port type | VGA |
| HDMI in | 2 |
| Number of HDMI outputs | 1 |
| VGA (D-Sub) ports quantity | 3 |
| VGA (D-Sub) input ports | 2 |
| VGA (D-Sub) output ports | 1 |
| Technical data | |
| Height packaging | 0.028m |
| Article height | 2.50cm |
| Inputs x outputs | 2x1 |
| Net weight | 0.209kg |
| Packaging volume | 0.0040m³ |
| Article width | 9.00cm |
| Weight | 0.233kg |
| Length packaging | 0.150m |
| Product note | <h3>Note on pin assignment:</h3><p>The switch does not switch all 15 contacts of the Sub-D connectors on a 1:1 basis.</p><p>Pins 1, 2, 3, 12, 13, 14 and 15 are each switched on a 1:1 basis. Pins 4, 9 and 11 are not assigned. Pins 5, 6, 7, 8 and 10 are connected to each other and to the connector shield/earth.</p> |
| Width packaging | 0.950m |
| Article type | VGA switch |
| Article length | 14.50cm |
| Weight & dimensions | |
| Width | 90 mm |
| Depth | 145 mm |
| Height | 25 mm |
| Weight | 209 g |
| Dimensions (WxDxH) | 90 x 145 x 25 mm |
