Iiyama TF3215MC-B2AG ProLite , 24/7, 80cm (31,5''), Projected Capacitive, Full HD, kit (USB), black
|
1.022,76 EUR |
|
|
( 1.217,08 EUR incl. VAT ) ≈ £856.05 | ≈ $1,140.38 plus delivery charges: 148,00 € |
|
| Delivery time from supplier's stock (ca.) 3 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1064864 |
| Mfg Part No: | TF3215MC-B2AG |
| Weight: | 12.85 kg |
Product information for Iiyama TF3215MC-B2AG:
touch monitor (open-frame, 16:9), screen size: 80 cm (31.5''), Projected Capacitive, multi touch, resolution: 1920x1080 pixels, VESA mount (200x200 mm), response time: 8ms, brightness 425cd, contrast: 3000:1, antiglare, connection: VGA, display-port, HDMI, touch interface: USB, incl.: cable (USB, HDMI), power supply unit, power cable (EU), QSG, colour: black
| Design | |
| Market positioning | Business |
| Product colour | Black |
| Housing material | Metal |
| Front bezel colour | Black |
| Glass thickness | 6 mm |
| Display | |
| Display diagonal | 80 cm (31.5") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Panel type | VA |
| Touchscreen type | Kiosk |
| Touchscreen technology | Projected capacitive system |
| Touch technology | Multi-touch |
| Number of simultaneous touchpoints | 30 |
| Display brightness (typical) | 500 cd/m² |
| Display brightness | 425 cd/m² |
| Response time | 8 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Screen shape | Flat |
| Contrast ratio (typical) | 3000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.3637 x 0.3637 mm |
| Horizontal scan range | 30 - 68 kHz |
| Viewable size, horizontal | 69.8 cm |
| Viewable size, vertical | 39.3 cm |
| Digital horizontal frequency | 30 - 68 kHz |
| Display diagonal (metric) | 80 cm |
| Surface hardness | 6H |
| Colour depth | 8 bit |
| Touchscreen | |
| Anti-glare screen | |
| Ergonomics | |
| Panel mounting interface | 200 x 200 mm |
| On Screen Display (OSD) languages | Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Number of OSD languages | 7 |
| VESA mounting | |
| Cable management | |
| On Screen Display (OSD) | |
| Plug and Play | |
| Logistics data | |
| Products per pallet | 21 pc(s) |
| Pallet net width | 100 cm |
| Pallet net length | 120 cm |
| Pallet net height | 2.04 m |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Other features | |
| International Protection (IP) code | IP65 |
| IK code | IK07 |
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Positional accuracy | 2 mm |
| User controls | contrast, brightness, auto adjust, H.position, V.position, phase, OSD H.position, OSD V.position, OSD timeout, reset, input select, OSD language, colour temperature, sharpness, touch switch (normal, glove, through-glass) |
| Brightness | 425 cd/m² |
| Packaging content | Touch Panel Driver Disk (CD-ROM) |
| Active display area (W x H) | 698.4 x 392.8 mm |
| Touch method | finger, glove (latex), capacitive stylus |
| Weight | 10 kg |
| Height | 437 mm |
| Width | 743 mm |
| Depth | 61 mm |
| Control panel | Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power |
| Compliance certificates | REACH |
| Mean time between failures (MTBF) | 50000 h |
| Packaging content | |
| Cables included | AC, USB, HDMI |
| Quick start guide | |
| Packaging data | |
| Package width | 890 mm |
| Package depth | 155 mm |
| Package height | 630 mm |
| Package weight | 12.8 kg |
| Performance | |
| Operating hours (hours/days) | 24/7 |
| NVIDIA G-SYNC | |
| AMD FreeSync | |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Built-in USB hub | |
| USB Touch port | |
| HDMI | |
| HDCP | |
| Power | |
| Energy efficiency class (SDR) | F |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 27.4 kWh |
| Power consumption (typical) | 32 W |
| Power consumption (standby) | 0.7 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
| Technical details | |
| Native refresh rate | 60 Hz |
| Weight & dimensions | |
| Width (with stand) | 743 mm |
| Depth (with stand) | 61 mm |
| Height (with stand) | 437 mm |
| Weight (with stand) | 10 kg |
| Width (without stand) | 745.5 mm |
| Depth (without stand) | 61 mm |
| Height (without stand) | 437 mm |
| Weight (without stand) | 10 kg |
