TFT-Touch 247,7 cm ( 97,5 inch )/247,7cm iiyama ProLite TE9812MIS - 24/7 *schwarz*
|
3.628,61 EUR |
|
|
( 4.318,05 EUR incl. VAT ) ≈ £3,037.15 | ≈ $4,045.90 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 534812 |
| Mfg Part No: | TE9812MIS-B3AG |
| UPC/EAN: | 4948570123728 |
| Weight: | 0 kg |
Product information for Iiyama TE9812MIS-B3AG:
• Diagonale: 247,7 cm ( 97,5 inch )/247,7cm • Auflösung: 3840x2160, 16:9 • Helligkeit: 350cd/m² • Kontrast: 1200:1 (typisch) • Reaktionszeit: 8ms • Blickwinkel: 178°/178° • Panel: IPS • Anschlüsse: 1x USB-C, 3x HDMI, 1x VGA, 1x Mini Jack, 1x RS-232c, 2x RJ-45, 1x IR, 1x RCA, 5x USB-A • VESA: 800x600 • Abmessungen (BxHxT): 2244,5 x 1323 x 92mm
| Audio | |
| Number of built-in speakers | 2 |
| RMS rated power | 32 W |
| Built-in speaker(s) | |
| Certificates | |
| Certification | CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, EPA 8.0 |
| Computer system | |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| Processor model | A55 |
| Processor architecture | ARM Cortex-A55 |
| Processor cores | 4 |
| Internal memory | 8 GB |
| On-board graphics card model | ARM Mali-G52 |
| Internal storage capacity | 64 GB |
| Operating system installed | Android 11 |
| Built-in processor | |
| Design | |
| Product design | Kiosk design |
| Placement supported | Indoor |
| Orientation | Horizontal |
| Product colour | Black |
| Panel mounting interface | 800 x 600 mm |
| Bezel width (bottom) | 3.1 cm |
| Bezel width (side) | 1.65 cm |
| Bezel width (top) | 1.65 cm |
| Bezel colour | Black |
| VESA mounting | |
| Anti-glare screen | |
| Display | |
| Panel type | IPS |
| Display diagonal | 2.48 m (97.5") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 400 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen technology | PureTouch-IR |
| Number of simultaneous touchpoints | 40 |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 4000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.562 x 0.562 mm |
| Active display area (W x H) | 2158.8 x 1214.4 mm |
| Display diagonal (metric) | 247.7 cm |
| Horizontal scan range | 30 - 135 kHz |
| Native refresh rate | 60 Hz |
| Surface hardness | 7H |
| Glass thickness | 3 mm |
| Glass film | AG/AR Film |
| Touchscreen | |
| Logistics data | |
| Products per pallet | 4 pc(s) |
| Network | |
| Ethernet LAN data rates | 1000 Mbit/s |
| Wi-Fi standards | Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b |
| Ethernet LAN | |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | -20 - 60% |
| Storage temperature (T-T) | -20 - 60 °C |
| Other features | |
| Bluetooth version | 5.0 |
| Brightness | 350 cd/m² |
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Power supply type | Internal |
| Quick start guide | |
| Bluetooth | |
| Packaging content | |
| Number of stylus pens | 4 |
| Cables included | AC, USB, HDMI |
| Remote control included | |
| Batteries included | |
| Stylus pen | |
| Wi-Fi module included | |
| Packaging data | |
| Package width | 2406 mm |
| Package depth | 280 mm |
| Package height | 1474 mm |
| Package volume | 128100 cm³ |
| Package weight | 128.1 kg |
| Performance | |
| Purpose | Commercial |
| On Screen Display (OSD) languages | Czech, Danish, German, English, Spanish, Finnish, French, Italian, Norwegian, Dutch, Polish, Russian, Swedish |
| Operating hours (hours/days) | 24/7 |
| HDCP version | 2.2 |
| Mean time between failures (MTBF) | 50000 h |
| On Screen Display (OSD) | |
| HDCP | |
| Ports & interfaces | |
| HDMI ports quantity | 4 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| USB ports quantity | 5 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 3 |
| USB Power Delivery up to | 65 W |
| Ethernet LAN (RJ-45) ports | 1 |
| Remote (IR) input | 1 |
| DVI port | |
| USB port | |
| USB Power Delivery (USB PD) | |
| RS-232 interface | |
| RS-232C | |
| Audio Return Channel (ARC) | |
| Power | |
| Power consumption (typical) | 233 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 233 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Technical details | |
| Playback media | Y |
| User controls | general settings (input, volume, backlight), audio settings (volume, bass, treble, balance, sound mode, mute), screen settings (aspect ratio, pixel shift), display settings (brightness, contrast, hue, sharpness, display mode, colour temp.), adjust settings (H-position, V-position, clock, phase, auto), settings (wireless & networks, personal, input & output, application, system) |
| Sustainability certificates | ErP |
| Warranty period | 5 year(s) |
| Compliance certificates | CB, CE, EAC, REACH, RoHS, TÜV mark, WEEE |
| Audio in (mini jack) | |
| Weight & dimensions | |
| Display width | 2244.5 mm |
| Display depth | 92 mm |
| Display height | 1323 mm |
| Display weight | 98.5 kg |
| Width | 2244.5 mm |
| Depth | 92 mm |
| Height | 1323 mm |
| Weight | 98.5 kg |
| Width (with stand) | 2244.5 mm |
| Depth (with stand) | 92 mm |
| Height (with stand) | 1323 mm |
| Weight (with stand) | 98.5 kg |
Questions & answers
What is the delivery time of TFT-Touch 247,7 cm ( 97,5 inch )/247,7cm iiyama ProLite TE9812MIS - 24/7 *schwarz*?
The article TFT-Touch 247,7 cm ( 97,5 inch )/247,7cm iiyama ProLite TE9812MIS - 24/7 *schwarz* is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Iiyama TE9812MIS-B3AG to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you TFT-Touch 247,7 cm ( 97,5 inch )/247,7cm iiyama ProLite TE9812MIS - 24/7 *schwarz* always at the best possible price. We can give you a discount of 2% on TFT-Touch 247,7 cm ( 97,5 inch )/247,7cm iiyama ProLite TE9812MIS - 24/7 *schwarz* if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
