Helukabel 15022 HELU JZ-HF 5G0.75sqmm Gray drag chain cable PVC
|
1,70 EUR |
|
|
incl. 0,27 EUR copper surcharge ( 2,02 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1101418 |
|---|---|
| Mfg Part No: | 15022 |
| UPC/EAN: | 4060892124518 |
| Weight: | 0 kg |
Product information for Helukabel 15022:
Technical data:
Special PVC hose cable, highly flexible due to special construction and designin accordance with DIN VDE 0285-525-2-51 / DIN EN 50525-2-51
Temperature range moving -10°C to +80°C stationary -40°C to +80°C
Nominal voltage U0/U 300/500 V
Test voltage 4000 V
Breakdown voltage min. 8000 V
Minimum bending radius moving 7.5x cable Ø stationary 4x cable Ø
Radiation resistance up to 80x106 cJ/kg (up to 80 Mrad)
Construction:
Bare copper wire, extra fine wire in accordance with VDE 0295 Cl.6 Sp.4, BS 6360 cl.6 or IEC 60228 cl.6
Core insulation made of special PVC
Core identification in accordance with DIN VDE 0293 black cores with continuous white number print
Cores twisted in layers with optimal lay lengths
Fleece wrapping over each twist layer
Outer jacket made of special PVC
Jacket color: gray (RAL 7001) with meter marking
Properties:
The materials used in production are silicone and cadmium-free and free from substances that impair paint wetting
Tests:
PVC self-extinguishing and flame-retardant according to DIN VDE 0482-332-1-2 / DIN EN 60332-1-2 / IEC 60332-1-2
Oil-resistant according to DIN VDE 0473-811-404/DIN EN 60811-404
Notes:
'Cleanroom qualified\lashshielded analogue type: JZ-HF-CY
with UL approval MULTISPEED 500-PVC UL/CSA
Use:
Used for installation in dry and damp rooms, but not outdoors as a highly flexible PVC control cable, for frequent lifting and Bending stress in machine and tool construction, in robot technology and on permanently moving machine parts. Proven to be effective in drag chain applications with free movement without tensile stress and without forced movement control.
Standard lengths: 100 m, 500 m, 1000 m
Subject to technical changes.
Type: JZ-HF 5G0,75qmm
The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.
Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
