Helukabel 11053-100 HELU PVC hose cable JB-500 4G1 mm² Standard length: 100 M
|
111,93 EUR |
|
|
incl. 28,77 EUR copper surcharge ( 133,20 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Sales unit: 100 meters | |
| Lieske Part No.: | 2121904 |
|---|---|
| Mfg Part No: | 11053-100 |
| Weight: | 0 kg |
Product information for Helukabel 11053-100:
Technical data:
Special PVC hose cable based on DIN VDE 0285-525-2-11 / DIN EN 50525-2-11Temperature range moving -15°C to +80°C stationary -40°C to +80°C
Nominal voltage U0/U 300/500 V
Test voltage 4000 V
Breakdown voltage min. 8000 V Minimum
bending radius moving 7.5x cable Ø stationary 4x cable Ø
Radiation resistance up to 80x106 cJ/kg (up to 80 Mrad)
Structure:
Bare copper wire, according to DIN VDE 0295 cl.5, fine-wire, BS 6360 cl.5, IEC 60228 cl.5
Core insulation made of special PVC
Core identification according to JB/OB color code
Cores stranded in layers with optimal lay lengths
Outer sheath made of Special PVC
sheath color: gray (RAL 7001) with meter marking
Properties:
Largely oil-resistant, oil/chemical resistance,
conditionally suitable for drag chains, conditionally suitable for torsion
The materials used in production are silicone- and cadmium-free and free from substances that impair paint wetting
Tests:
PVC self-extinguishing and flame-retardant in accordance with DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1-2
Notes:
shielded analog type: Y-CY-JB
Use:
Used for medium mechanical stress for flexible applications with free movement without tensile stress and without forced movement in dry, damp and wet rooms, but not outdoors, as a measuring, monitoring and control cable on machine tools, assembly lines and conveyor belts, production lines, in plant engineering, in heating and air conditioning technology.
Standard lengths: 100 m, 500 m, 1000 m
Technical changes reserved.
Type: JB-500
The item price shown refers to 100 meters Helukabel 11053-100
Questions & answers
What is the delivery time of Helukabel 11053-100 HELU PVC hose cable JB-500 4G1 mm² Standard length: 100 M?
The article Helukabel 11053-100 HELU PVC hose cable JB-500 4G1 mm² Standard length: 100 M is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Helukabel 11053-100 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Helukabel 11053-100 HELU PVC hose cable JB-500 4G1 mm² Standard length: 100 M always at the best possible price. We can give you a discount of 2% on Helukabel 11053-100 HELU PVC hose cable JB-500 4G1 mm² Standard length: 100 M if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
How many units does the article contain?
Helukabel 11053-100 HELU PVC hose cable JB-500 4G1 mm² Standard length: 100 M is offered by us in a sales unit of 100 meters If you need a larger quantity, you can contact us at any time. We will make a special offer for you
