Fränkische Rohrwerke Logo

Fränkische Rohrwerke 23170032 Fränkische clipfix-H0 32 plastic clamp grey

Your rating:
Average rating
product review for Fränkische Rohrwerke 23170032 Fränkische clipfix-H0 32 plastic clamp grey
( 4.5 / 5 ) 31 ratings
Fränkische Rohrwerke 23170032
This image may differ from the desired article.
Fränkische Rohrwerke 23170032Fränkische Rohrwerke 23170032
123,02 EUR 128,21 EUR
( 146,39 EUR incl. VAT )
≈ £102.97  |  ≈ $135.20
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
Sales unit: 50 pieces
1x Fränkische Rohrwerke 23170032 Fränkische clipfix-H0 32 plastic clamp grey
Lieske Part No.:629981
Mfg Part No: 23170032
UPC/EAN: 4013960180398
Weight:0.495 kg
Type:clipfix-H0 32
Graduated prices net
From piecesPrice per pieces
5118,41 EUR
10113,79 EUR
15109,18 EUR
20104,57 EUR

Product information for Fränkische Rohrwerke 23170032:

The clipfix-H0 32 is a plastic clamp from manufacturer Fränkische Rohrwerke, specifically designed for securing plastic installation pipes. It is made of PPE (polyphenylene ether) and is finished in grey (RAL 7035). The clamp is non-flame propagating and 100 % halogen-free according to DIN VDE V 0604-2-100, making it suitable for use in installations with increased safety requirements. The low smoke development during fires improves visibility in escape and rescue routes, as no dense smoke clouds are formed. Additionally, no toxic or corrosive gases are produced, as the clamp is halogen-free.

Applications

The clipfix-H0 32 is used for securing plastic straight pipes of types FPKu-EM-F-LS0H Low Smoke and FPKu-EM-F-H0, as well as all corrugated pipes. It is particularly suitable for installations in buildings where smoke development and the formation of toxic gases during a fire must be minimized, for example in hospitals, administrative buildings, or public facilities. The clamp is designed for mounting on C-profile rails with a width of 10 mm, enabling flexible and modular fastening.

Functions and Equipment in Detail

The clamp is stackable and alignable, allowing for continuous fastening along the rail. Installation is achieved via an integrated clip mechanism, ensuring secure and quick mounting. For nominal sizes 40, 50, and 63 mm, additional clipsib securing brackets are included, providing extra stabilization for pipe connections. These securing brackets are not intended for nominal size 32 mm, as the clamp is supplied without additional brackets for this size.

Technology Explained Simply

The use of PPE as the material ensures high thermal resistance and mechanical strength. The clamp is non-flame propagating, meaning it does not burn independently when exposed to open flame, but only as long as the flame directly affects it. Halogen-free composition reduces the risk of toxic and corrosive gases forming during a fire, increasing safety in fire situations. Low smoke development improves visibility in escape and rescue routes, which is critical for evacuating people.

Compatibility and Accessories

The clipfix-H0 32 is specifically designed for use with plastic straight pipes FPKu-EM-F-LS0H Low Smoke and FPKu-EM-F-H0, as well as all corrugated pipes. Mounting is done on C-profile rails with a width of 10 mm. Under extreme operating conditions such as strong vibration, high temperatures, overhead mounting, or high weights, it is necessary to reduce the specified spacing between clamps or to use metal securing brackets (ASG-E). The clamp is not intended for use in environments with aggressive chemicals or strong mechanical loads without additional measures.

Installation and Mounting

Installation is performed by simply sliding the clamp onto the C-profile rail and then inserting the pipe into the clamp. The stackable and alignable design allows for continuous fastening along the rail. The clamp is designed for quick and secure installation without tools. During installation planning, the prescribed spacing between clamps must be observed, which may vary depending on load and environmental conditions.

Operational Advantages

The halogen-free and non-flame propagating properties of the clipfix-H0 32 increase safety in fire situations. Low smoke development improves visibility and facilitates evacuation. The use of PPE ensures high mechanical and thermal stability. The stackable and alignable design enables flexible and modular installation. The clamp is suitable for use in installations with high safety requirements, particularly in buildings where fire prevention and evacuation safety are of special importance.

The item price shown refers to 50 pieces Fränkische Rohrwerke 23170032
General
MaterialPPE
ColourGrey
Colour codeRAL 7035
Degree of protectionnon-flame propagating
Halogen-free100 % halogen-free
NormDIN VDE V 0604-2-100
CompatibilityPlastic conduit FPKu-EM-F-LS0H Low Smoke, FPKu-EM-F-H0, corrugated conduits
MountingC-profile rail 10 mm
Mounting methodstackable and modular
Nominal width32 mm


Questions & answers

What is the delivery time of Fränkische Rohrwerke 23170032 Fränkische clipfix-H0 32 plastic clamp grey ?

The article Fränkische Rohrwerke 23170032 Fränkische clipfix-H0 32 plastic clamp grey is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Fränkische Rohrwerke 23170032 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Fränkische Rohrwerke 23170032 Fränkische clipfix-H0 32 plastic clamp grey always at the best possible price. We can give you a discount of 2% on Fränkische Rohrwerke 23170032 Fränkische clipfix-H0 32 plastic clamp grey if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 5 pieces of Fränkische Rohrwerke 23170032 Fränkische clipfix-H0 32 plastic clamp grey we can offer you a price of 118,41 EUR per piece. The more you buy, the cheaper the article will be.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.

How many units does the article contain?

Fränkische Rohrwerke 23170032 Fränkische clipfix-H0 32 plastic clamp grey is offered by us in a sales unit of 50 pieces If you need a larger quantity, you can contact us at any time. We will make a special offer for you
