Faber Kabel 114740400000 NA2XS (F) 2Y 1x70RM/16 12/20kV, medium voltage according to VDE 0276-620
|
19,49 EUR |
|||||||||||
|
incl. 1,64 EUR copper surcharge ( 23,19 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 436646 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 114740400000 | ||||||||||
| Weight: | 0 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Faber Kabel 114740400000:
The cables are designed for high thermal loads during operation. Due to the good laying characteristic, the cables can be laid easily in difficult line guideways.
Conductor Material: Aluminum
Conductor class: 2 = stranded
Insulation: PU DIX8
Sheath material: polyethylene DMP2
Laminated sheath: Yes
Flame retardant: No
maximum permissible conductor temperature: 70 ° C
Perm. Operating temperature, fixed: +70 ° C
Perm. Operating temperature, moving: -20 ° C - +70 ° C
Bending radius, fixed: 15x outer diameter
Partial discharge: 2pc
Nominal voltage U: 20kV
Nominal voltage U0 12 kV
The maximum voltage in three-phase systems: 24kV
Type: NA2XS (F) 2Y 1X70RM/16 12/20kV item: 1 MTR
Type: NA2XS(F)2Y 1X70RM/16
The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.
Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
Questions & answers
What is the delivery time of Faber Kabel 114740400000 NA2XS (F) 2Y 1x70RM/16 12/20kV, medium voltage according to VDE 0276-620?
The article Faber Kabel 114740400000 NA2XS (F) 2Y 1x70RM/16 12/20kV, medium voltage according to VDE 0276-620 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Faber Kabel 114740400000 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Faber Kabel 114740400000 NA2XS (F) 2Y 1x70RM/16 12/20kV, medium voltage according to VDE 0276-620 always at the best possible price. We can give you a discount of 2% on Faber Kabel 114740400000 NA2XS (F) 2Y 1x70RM/16 12/20kV, medium voltage according to VDE 0276-620 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 25 meters of Faber Kabel 114740400000 NA2XS (F) 2Y 1x70RM/16 12/20kV, medium voltage according to VDE 0276-620 we can offer you a price of 18,42 EUR per piece. The more you buy, the cheaper the article will be.
You can also send us a price proposal for your desired quantity of Faber Kabel 114740400000 NA2XS (F) 2Y 1x70RM/16 12/20kV, medium voltage according to VDE 0276-620 via the form price proposal. Enter your name, contact details, price and quantity you need. Our sales team will then send you a good quotation immediately.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
