Faber Kabel 013987 N2XH-J 1X6 RE B2 low voltage cable halogen-free

Application: Wherever special protection against fire and fire damage is required for people and property and where high safety requirements must be met. Indoors and outdoors. Do not lay directly in the ground or water. In the event of flames, they prevent the spread of a fire and develop very little smoke. No release of corrosive and toxic gases. They are considered to be protectively insulated. Structure: Conductor: bare copper conductor in accordance with VDE 0295, RE (round single-wire) or RM (round multi-wire), > 50 mm² are compacted. Core insulation: cross-linked polyethylene 2XI1. Core identification: in accordance with VDE 0293-308. Filling jacket. Outer jacket: polymer mixture: halogen-free in accordance with VDE 0207 T. 24. Jacket color: black. Technical data: Nominal voltage: 0.6/1 kV. Test voltage: 4000 V. Temperature range: -5 °C - +70 °C (during installation) -30 °C - +70 °C (after installation). Operating temperature: +90 °C (max.). Bending radius: 15 x cable diameter (single-core), 12 x cable diameter (multi-core). Tests: Burning behavior: according to VDE 0472 T. 804, test type C (=IEC 332-3). Corrosiveness of combustion gases: according to VDE 0472 T. 813. Smoke gas density: according to VDE 0472 T. 816, test type C (=IEC 1034-1). Halogen-free: according to VDE 0472 T. 815. Ozone resistance: according to VDE 0472 T. 805. Properties: halogen-free, low fire propagation, minimal smoke development, no corrosive gases, do not lay directly in soil or water. Other core numbers and cross-sections on request.
Type: N2XH-J 1X6 RE var.
