Eaton 256209 XT-CPU-BAT1 battery

Your rating:
Average rating
product review for Eaton 256209 XT-CPU-BAT1 battery
( 4.4 / 5 ) 37 ratings
Eaton 256209
This image may differ from the desired article.
Eaton 256209Eaton 256209
-11% 34,25 EUR 38,56 EUR
( 40,76 EUR incl. VAT )
≈ £28.67  |  ≈ $37.64
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Eaton 256209 XT-CPU-BAT1 battery
Lieske Part No.:170705
Mfg Part No: 256209
UPC/EAN: 4015082562090
Weight:0.123 kg
Type:XT-CPU-BAT1

Product information for Eaton 256209:

The XT-CPU-BAT1 battery from Eaton, manufacturer's number 256209, is a replacement or exchange battery element for the XC100/200 modular controller. It is designed for buffering the real-time clock and storing remanent data that must be retained in the event of a power failure. The battery is specifically designed for use in industrial automation systems, where continuous time and data retention is required even when the main power supply is interrupted.

Functions and equipment in detail
The XT-CPU-BAT1 ensures the functionality of the real-time clock within the XC100/200 controller, so that the clock continues to run correctly after a power failure. Additionally, it ensures that remanent data stored in the controller’s memory – such as configuration settings, parameters, or status information – is not lost. This function is particularly important in systems requiring high operational reliability and data integrity. The battery is designed for a voltage of 3.6 V, which meets the requirements of the controller unit.

Technology explained simply
The battery operates as a backup power source for the internal power supply of the controller. In the event of a failure of the main voltage, the XT-CPU-BAT1 takes over the power supply for the real-time clock and the memory area that stores remanent data. The voltage of 3.6 V is optimized for compatibility with the internal circuitry of the XC100/200 controller. The battery is not intended for the main power supply of the controller, but exclusively for buffering the specified functions.

Compatibility and accessories
The XT-CPU-BAT1 battery is specifically developed for Eaton’s XC100 and XC200 modular controllers. It can be directly installed into these controller units without requiring additional adapters or converters. Use in other control systems is not intended and not guaranteed.

Mounting and installation
Installation is carried out by directly inserting the battery into the designated holder within the controller unit. Mounting does not require any special tools or additional components. The battery is designed to fit securely into the controller unit and is held firmly in place.

Advantages in operation
By using the XT-CPU-BAT1, it is ensured that the real-time clock and remanent data remain intact even during short-term power failures. This is crucial for operational reliability and for restoring the operational state after a power failure. The battery enables reliable and continuous operation of the controller unit without requiring manual intervention or reconfiguration.

General
Battery voltage3,6 V
Functionbuffering of real-time clock and non-volatile data
CompatibilityXC100/200


Questions & answers

What is the delivery time of Eaton 256209 XT-CPU-BAT1 battery ?

The article Eaton 256209 XT-CPU-BAT1 battery is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Eaton 256209 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Eaton 256209 XT-CPU-BAT1 battery always at the best possible price. We can give you a discount of 2% on Eaton 256209 XT-CPU-BAT1 battery if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
