DRAGINO · Sensor · LoRa · LoRaWAN 0~20mA, 0~ 30v sensor LoRaWAN Analog Sensor · PS-LB-NA-EU868-12
|
55,69 EUR 56,65 EUR |
|
|
( 66,27 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 2073157 |
|---|---|
| Mfg Part No: | PS-LB-NA-EU868-12 |
| Weight: | 0.37 kg |
Product information for DRAGINO PS-LB-NA-EU868-12:
PS-LB series sensors include thread installation and immersion types, they support different pressure ranges, which can be used for different measurement needs.
The LoRa wireless technology used in the PS-LB allows the device to send data and achieve extremely long ranges at low data rates. It offers spread spectrum communication with extremely long range and high interference immunity with minimal power consumption.
PS-LB supports BLE configuration and over-the-air OTA updates, making it easier for users to use.
PS-LB is powered by an 8500mAh Li-SOCI2 battery, designed for long-term use of up to 5 years.
Each PS-LB is pre-installed with a set of unique keys for LoRaWAN registrations. Register these keys on the local LoRaWAN server and the connection will be established automatically after power on.
This sensor has a waterproof (IP68) M12 opening for external probes. For measuring air or water pressure, please use the following items: 217626, 217627 or 217628Features: LoRaWAN 1.0.3 Class A Ultra-low power consumption Measuring air, gas or water pressure Various pressure ranges available Thread installation type or immersion type Battery level monitoring Bandwidths : EU868 Supports Bluetooth v5.1 and LoRaWAN remote configuration Supports OTA wireless update firmware Uplink at regular intervals Downlink to change configuration 8500mAh battery for long-term operation Specifications: Micro Controller: MCU: 48Mhz ARM Flash: 256KB RAM: 64KB Common DC Characteristics: Supply voltage: 2.5v ~ 3.6v Operating temperature: -40 ~ 85°C LoRa Spec: Frequency range Band 1 (HF): 862 ~ 1020 Mhz Max +22 dBm constant RF output vs. RX Sensitivity: up to -139 dBm. Excellent blocking immunity Current input measurement: Range: 0 ~ 20mA Accuracy: 0.02mA Resolution: 0.001mA Voltage input measurement: Range: 0 ~ 30v Accuracy: 0.02v Resolution: 0.001v Battery: Li/SOCI2 non-rechargeable battery Capacity: 8500mAh Self-discharge: < / Year @ 25°C Max. continuous current: 130mA Max. current: 2A, 1 second Power consumption: Sleep Mode: 5uA @ 3.3v LoRa Transmit Mode: 125mA @ 20dBm, 82mA @ 14dBm
Questions & answers
What is the delivery time of DRAGINO · Sensor · LoRa · LoRaWAN 0~20mA, 0~ 30v sensor LoRaWAN Analog Sensor · PS-LB-NA-EU868-12?
The article DRAGINO · Sensor · LoRa · LoRaWAN 0~20mA, 0~ 30v sensor LoRaWAN Analog Sensor · PS-LB-NA-EU868-12 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 6 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of DRAGINO PS-LB-NA-EU868-12 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you DRAGINO · Sensor · LoRa · LoRaWAN 0~20mA, 0~ 30v sensor LoRaWAN Analog Sensor · PS-LB-NA-EU868-12 always at the best possible price. We can give you a discount of 2% on DRAGINO · Sensor · LoRa · LoRaWAN 0~20mA, 0~ 30v sensor LoRaWAN Analog Sensor · PS-LB-NA-EU868-12 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
