Dold 0056504 BL5922.08/031 DC24V emergency stop monitor

Your rating:
Average rating
product review for Dold 0056504 BL5922.08/031 DC24V emergency stop monitor
( 4.6 / 5 ) 13 ratings
Dold 0056504
This image may differ from the desired article.
559,57 EUR
( 665,89 EUR incl. VAT )
≈ £468.36  |  ≈ $614.97
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Dold 0056504 BL5922.08/031 DC24V emergency stop monitor
Datasheet:file_download Download
Lieske Part No.:905160
Mfg Part No: 0056504
UPC/EAN: 4030641565046
Weight:0.52 kg
Type:BL5922.08/031DC24V
Graduated prices net
From piecesPrice per pieces
3551,18 EUR
6542,78 EUR
9534,39 EUR
12526,00 EUR

Product information for Dold 0056504:

The Dold safety relay BL5922.08/031DC24V is an emergency stop monitor for use in industrial safety applications. It is designed for monitoring emergency stop pushbuttons in machines, production lines, and plants, particularly in safety circuits of conveyor systems, packaging machines, and automated manufacturing systems. The device enables 2-channel monitoring of up to 8 emergency stop pushbuttons and is rated for a nominal voltage of DC 24 V. The module width is 90 mm, making it suitable for use in standard control panels.

Applications
This device is used in safety-critical installations where the reliability of the emergency stop function is essential. It monitors the status of emergency stop pushbuttons and indicates the trigger point to enable quick fault analysis and re-commissioning. The application is in systems requiring cross-fault-safe 2-channel monitoring, where emergency stop pushbuttons can be directly connected to the device.

Functions and equipment in detail
The BL5922.08/031DC24V provides 2-channel monitoring with direct connection of emergency stop pushbuttons. The maximum number of monitored pushbuttons is 8 in 2-channel operation. The status is indicated via LEDs, which visually display the status of individual pushbuttons. When pushbuttons are not actuated, the green LEDs are illuminated; when a pushbutton is actuated, the corresponding LED turns off. The pushbuttons are connected in series, so that in case of multiple simultaneous actuations, only the first in the chain is signaled. The device features an adjustable memory behavior: without bridge X1/X2, a manual reset is required; with bridge X1/X2, an automatic reset occurs. An integrated RESET button and the option for remote reset enable quick reactivation of the system.

Technology explained simply
The technology is based on a serial wiring of emergency stop pushbuttons, where the device monitors the signals and identifies the trigger position. The BCD-coded output interface with positive logic enables unambiguous coding of the triggered pushbutton. The maximum number of inputs is 16, with expansion possible in steps of 8 or 16 pushbuttons. The nominal voltage of DC 24 V is typical for industrial control systems and ensures stable operating voltage. The module width of 90 mm corresponds to the standard for modular control panels.

Compatibility and accessories
The device is designed for direct connection of emergency stop pushbuttons and can be used in systems requiring cross-fault-safe 2-channel monitoring. It is part of the SAFEMASTER series from Dold and can be combined with other devices in this series to build larger monitoring systems. It is used without a fieldbus interface, making it suitable for applications that do not require CANopen connectivity.

Mounting and installation
Mounting is done in standard control panels with a module width of 90 mm. Wiring of the emergency stop pushbuttons is simple and is done directly to the device inputs. The connection options are designed for 2-channel systems, with pushbuttons connected in series. The positioning of the LEDs allows for quick visual inspection of the system status. Installation requires no additional components, as the device integrates all necessary functions for monitoring and signaling.

Advantages in operation
Operation of the BL5922.08/031DC24V is characterized by clear signaling and easy reactivation. The LED display enables immediate identification of the triggered pushbutton, reducing maintenance and re-commissioning times. The adjustable memory behavior offers flexibility depending on system requirements. Direct wiring of pushbuttons reduces installation complexity and minimizes error sources. The reliability of monitoring ensures plant safety and meets requirements for industrial safety systems.

Technical data
1- / 2-channel1, 2
Inputs max.16
Width90 mm
TypeBL 5922
Variant
Connection facilitiesdual-channel for 8 emergency stop buttons
Nominal voltageDC 24 V
VariantWithout fieldbus interface. Connection of e-stop button 2-channel, 2-channel monitoring when cross fault monitoring. With BCD output, high active


Product data sheet
Datasheet for Dold 0056504, EAN: 4030641565046
