Dold 0056356 SP9271.12 AC/DC24V 1-10A undercurrent relay Tv=0.1-20 s

Your rating:
Average rating
product review for Dold 0056356 SP9271.12 AC/DC24V 1-10A undercurrent relay Tv=0.1-20 s
( 4.3 / 5 ) 6 ratings
Dold 0056356
This image may differ from the desired article.
408,55 EUR
( 486,17 EUR incl. VAT )
≈ £341.96  |  ≈ $449.00
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Dold 0056356 SP9271.12 AC/DC24V 1-10A undercurrent relay Tv=0.1-20 s
Datasheet:file_download Download
Lieske Part No.:1312707
Mfg Part No: 0056356
UPC/EAN: 4030641563561
Weight:0.282 kg
Type:SP9271.12 AC/DC24V 1-10A
Graduated prices net
From piecesPrice per pieces
4405,49 EUR
8402,42 EUR
12399,36 EUR
16396,29 EUR

Product information for Dold 0056356:

The Dold undercurrent relay SP9271.12 AC/DC24V 1-10A is a 3-phase current monitoring device for alternating and rotating current networks. It is designed for continuous monitoring of current flow in industrial installations and switches off the output contacts according to the de-energized state principle when a set current value is undershot. The device is designed for use in enclosures and has a width of 70 mm. The auxiliary voltage is AC/DC 24 V, enabling flexible integration into existing control and protection systems.

Applications
This relay is designed for applications in industrial automation and energy distribution where reliable current monitoring is required. It is suitable, for example, for monitoring motors, pumps, heating systems, or other consumers with stable current demand. The 3-phase design allows simultaneous monitoring of all phases in a three-phase network, which is important for the safety and efficiency of installations.

Functions and equipment in detail
The device features two changeover contacts as output contacts, which are deactivated according to the de-energized state principle under undercurrent conditions. The pickup value is adjustable, allowing the threshold for undercurrent detection to be adapted to specific requirements. The switching delay is adjustable between 0.1 and 20 seconds to avoid unwanted tripping due to short-term current fluctuations. The hysteresis is fixed at approximately 4%, ensuring stable switching behavior. LED indicators signal the operating status: a green LED lights up when current is normal (good condition), and a red LED lights up under undercurrent conditions.

Technology explained simply
The relay operates on the de-energized state principle, in which the output contacts are deactivated rather than activated in the event of a fault (undercurrent). This is particularly useful in installations where load disconnection is required in the event of a fault. Galvanic isolation between the auxiliary circuit and the measurement circuit ensures high safety and prevents interference in the control circuit. The measurement ranges are fixed at 1 to 10 A, suitable for applications with medium current levels. Current measurement occurs in the frequency range of 50 to 400 Hz, enabling use in various networks.

Compatibility and accessories
The device is specified according to IEC/EN 60255-1 and carries the UKCA mark, confirming compliance with European safety and performance requirements. It is designed for use in enclosures and features top-mounted connection terminals suitable for mounting plates and cable ducts. The width of 70 mm allows installation in standard control panels. The auxiliary voltage of AC/DC 24 V is compatible with many industrial control and protection systems.

Mounting and installation
Mounting is carried out in enclosures using a mounting plate and cable duct. The top-mounted connection terminals facilitate wiring. Adjustment of the pickup value and switching delay is performed using the designated adjustment options on the device. The LED indicators support commissioning and maintenance, as the operating status can be visually checked.

Advantages in operation
The adjustable switching delay and adjustable pickup value allow precise adaptation to the specific application. Galvanic isolation between the measurement and auxiliary circuits increases safety. Clear signaling via LED indicators simplifies fault diagnosis. The de-energized state principle ensures that the load is switched off in the event of a fault, which is required in many industrial applications. Compliance with IEC/EN 60255-1 and the UKCA mark guarantee the reliability and safety of the device.

Technical data
1- / 3-phase3
Enclosure designSwitch cabinet
Output contacts2 C/O contacts
Width70 mm
TypeSP 9271
Operate delayYes
Variant
Auxiliary voltageAC/DC 24 V
Contact equipping2 changeover contacts
Measuring range1 - 10 A
Switching delay0,1 - 20 s
Approvals and MarkingsUKCA
Variant3-phase current relay. De-energized on trip


Product data sheet
Datasheet for Dold 0056356, EAN: 4030641563561
