Dold 0054364 IK9906.81 AC/DC12-240V 0.05S-300H time relay with delayed operation
|
101,81 EUR |
|||||||||||
|
( 121,15 EUR incl. VAT ) ≈ £85.21 | ≈ $111.89 plus delivery charges: 55,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 1583184 | ||||||||||
| Mfg Part No: | 0054364 | ||||||||||
| UPC/EAN: | 4030641543648 | ||||||||||
| Weight: | 0.123 kg | ||||||||||
| Type: | IK9906.81 AC/DC12-240V 0,05S-300H | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Dold 0054364:
Applications
This time relay is suitable for time-controlled processes in industrial automation, such as delays during start-up or shutdown operations, pump control, or lighting systems. The delayed-on function ensures that the output contact only switches after the set time has elapsed, contributing to safety and reliability in many applications. Control is achieved via 2-wire proximity switches, and for operating voltages above 24 V, a series resistor is recommended to limit inrush currents.
Functions and Equipment in Detail
The device features a changeover contact as the output contact, suitable for connecting loads. The delay time is adjusted via a rotary switch covering eight time ranges. An adjustment aid enables quick and precise setting of long times by using the blinking frequency of the yellow LED (1 second ± 4%) as a reference. The LED indicators signal operational readiness (green LED), contact position, and timing progress (yellow LED). The yellow LED blinks during the timing period and remains lit when the output relay is activated.
Technology Explained Simply
The time delay is implemented via an electronic circuit that starts the timing sequence upon activation through inputs A1/A2. The delay time can be finely adjusted using the rotary switch and a potentiometer. The connection terminals are designed for mounting in installation distributors, with the bottom arrangement of terminals allowing easy integration into existing control panels. The housing design is intended for use in installation distributors and complies with standards for such installations.
Compatibility and Accessories
The device can be equipped with a remote potentiometer (10 kΩ) connected via terminals Z1/Z2, enabling external fine adjustment of the delay time. The variant IK9906.81/500 additionally offers time interruption and time addition functions via control input B1(+), allowing the timing sequence to be interrupted at any time and resumed after reactivation. Control is performed with voltage relative to A2, with the operating voltage ranging from 12 to 240 V AC/DC.
Mounting and Installation
Mounting is carried out in installation distributors according to DIN 43880. The depth of 59 mm and the bottom-mounted terminals allow easy integration into existing control systems. The module width of 17.5 mm corresponds to the standard for modular components in electrical installations. The terminals are clearly labeled (A1, A2, 15, 16, 18, B1(+), Z1, Z2), ensuring unambiguous assignment.
Operational Advantages
The clear operation via rotary switch and LED indicators simplifies commissioning and maintenance. The adjustment aid using the LED blink frequency enables precise setting even for long delay times. Compatibility with 2-wire proximity switches and the ability to interrupt the timing sequence expand the range of applications. The UKCA certification confirms compliance with applicable European safety and performance requirements.
| Technical data | |
| Enclosure design | Distribution board |
| Output contacts | 1 C/O contact |
| Time function(s) | On-delay |
| Width | 17,5 mm |
| Type | IK 9906 |
| Connection facility for remote potentiometer | |
| Variant | |
| Contact equipping | 1 changeover contact |
| Nominal voltage | AC/DC 12 - 240 V |
| Time range | 0,05 - 300 h |
| Approvals and Markings | UKCA |
