Dold 0053547 IP5924.04 AC230V 50/60Hz emergency stop module
|
306,00 EUR |
|||||||||||
|
( 364,14 EUR incl. VAT ) ≈ £256.12 | ≈ $336.29 plus delivery charges: 55,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 1094057 | ||||||||||
| Mfg Part No: | 0053547 | ||||||||||
| UPC/EAN: | 4030641535476 | ||||||||||
| Weight: | 0.25 kg | ||||||||||
| Type: | IP5924.04 AC230V 50/60HZ | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Dold 0053547:
Applications
This safety relay is intended for use in industrial automation, particularly in areas requiring high safety standards. It is used to safely implement emergency stop functions, for example in production plants, machines with moving parts, or in combustion systems, as it complies with EN 50156-1 requirements. It is used in environments where safe shutdown in case of failure is necessary to prevent injuries or damage.
Functions and Equipment in Detail
The device supports single-channel or dual-channel wiring, allowing flexible use in various safety configurations. The output contacts consist of up to 4 normally closed contacts, suitable for controlling auxiliary contacts or loads. Connections are made via removable screw terminals, enabling easy installation and maintenance. The terminals are designed for wire connections, accommodating stranded wires with a cross-section up to 2.5 mm² and ferrules according to DIN 46228-1/-2/-3/-4. The width is 70 mm, allowing installation in standard control panels.
Technology Explained Simply
The safety relay IP5924.04 is designed for operation in safety-critical applications. It meets the requirements of EN ISO 13849-1 with Performance Level (PL) e and Category 4, representing the highest safety level for mechanical safety functions. Additionally, it complies with the Safety Integrity Level (SIL) 3 requirement (SIL CL) according to IEC/EN 62061 and Safety Integrity Level (SIL) 3 according to IEC/EN 61508, confirming the reliability and fault-free operation of the device in safety-relevant systems. LED indicators for Channel 1 / 2 and operational status enable visual monitoring of the device’s status. A short-circuit detection between terminal Y1 and ground provides additional safety by identifying potential faults in the circuit.
Compatibility and Accessories
The device is compatible with other components in the Dold product portfolio, particularly with emergency stop modules from the BG 5924 series, also designed for safety applications. Use in combination with other safety components enables the realization of complex safety functions. Galvanic isolation in the circuit ensures safe electrical separation between input and output, which is important for avoiding interference and ensuring plant safety.
Mounting and Installation
Mounting is carried out in standard control panels with a width of 70 mm. The removable screw terminals allow for easy and secure connection of wires. The terminals are designed for stranded wires with a cross-section up to 2.5 mm², and the use of ferrules according to DIN 46228-1/-2/-3/-4 is recommended. Installation must follow the manufacturer’s technical instructions to fully ensure safety functions.
Advantages in Operation
The safety relay offers high reliability and safety in safety-critical applications. Support for single- and dual-channel wiring enables flexible integration into existing systems. The LED indicators and short-circuit detection enhance operational safety by visually monitoring the device’s status and detecting potential faults early. Galvanic isolation in the circuit protects against electrical interference and ensures the integrity of the safety circuit. TÜV and UKCA certifications confirm compliance with applicable safety standards.
The device is designed for use in industrial environments where safe shutdown in case of failure is required. Technical features such as maximum thermal current load of 5 A and width of 70 mm are suitable for integration into standard control panels. Applications include plants requiring high safety standards, such as in manufacturing or energy supply industries.
| Technical data | |
| 1- / 2-channel | 1, 2 |
| Cat. / PL acc. to EN ISO 13849-1 | 4/e |
| Connection | Pluggable screw terminals |
| Output contacts max. | 4 NO contacts |
| SIL CL acc. to IEC/EN 62061 | 3 |
| SIL acc. to IEC/EN 62061 | 3 |
| Thermal current Ith max. | 5 A |
| Width | 70 mm |
| Type | IP 5924 |
| Variant | |
| Contact equipping | 4 NO contacts |
| Nominal voltage | AC 230 V 50/60 Hz |
| Approvals and Markings | TÜV, UKCA |
