Dold 0052649 BC7930N.81 AC/DC24V+AC230V 15-300S time relay delayed pickup

Your rating:
Average rating
product review for Dold 0052649 BC7930N.81 AC/DC24V+AC230V 15-300S time relay delayed pickup
( 4.4 / 5 ) 9 ratings
Dold 0052649
This image may differ from the desired article.
64,08 EUR
( 76,26 EUR incl. VAT )
≈ £53.63  |  ≈ $70.42
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Dold 0052649 BC7930N.81 AC/DC24V+AC230V 15-300S time relay delayed pickup
Datasheet:file_download Download
Lieske Part No.:257925
Mfg Part No: 0052649
UPC/EAN: 4030641526498
Weight:0.145 kg
Type:BC7930N.81AC/DC24V+AC230V15-300S
Graduated prices net
From piecesPrice per pieces
661,68 EUR
1259,27 EUR
2456,87 EUR
3654,47 EUR

Product information for Dold 0052649:

The Dold time relay BC7930N.81AC/DC24V+AC230V15-300S is an on-delay industrial time relay designed for time-controlled applications in enclosures. It features a 2-voltage version with rated voltage AC/DC 24 V and AC 230 V, enabling flexible use in various electrical systems. The time delay is continuously adjustable in the range of 15 to 300 seconds, making it suitable for applications requiring precise time control, such as delaying start-up processes, synchronizing machines, or securing operational sequences. The device complies with standard EN 61812-1 and is therefore approved for use in industrial control systems.

Applications
This time relay is intended for use in industrial control and automation systems, particularly in installations requiring time-controlled switching functions. Typical applications include delaying motor start-up, controlling lighting systems, synchronizing production processes, or securing operational sequences in machine building and manufacturing technology. The on-delay function ensures that the output contact only switches after the set delay time has elapsed, which is required in many industrial processes to control and synchronize switching operations.

Functions and Equipment in Detail
The device features a changeover contact as the output contact, rated for an operating voltage of AC 250 V. The contact configuration allows both make and break functions, enabling the relay to be used in various switching configurations. The repeatability is ≤ 0.5 % + 10 ms, ensuring high precision in repeated switching operations. An LED indicator signals the state of the output relay – it lights up when contacts 15–18 are closed, enabling visual monitoring of the operating status. The time delay is continuously adjustable from 15 to 300 seconds, with adjustment via a rotary knob.

Technology Explained Simply
The on-delay function means that the relay does not switch immediately upon application of the operating voltage, but only after the set delay time has elapsed. This is particularly useful for protecting motors after start-up or for activating multiple components in a system sequentially. The 2-voltage version allows supply from two different voltage sources: AC/DC 24 V (at terminals A3–A2) and AC 230 V (at terminals A1–A2). The operating voltage can be selected according to application requirements, with voltage ranges of 0.8 to 1.1 U_N (AC) and 0.9 to 1.25 U_N (DC). The nominal frequency is 50/60 Hz, enabling use in European and international power grids.

Compatibility and Accessories
The time relay is designed for mounting on a DIN rail in accordance with IEC/EN 60715, enabling quick and secure installation in enclosures. The terminals are designed for wire connections: 1 x 4 mm² solid conductor, 1 x 2.5 mm² stranded wire with sleeve and plastic collar, or 2 x 1.5 mm² stranded wire with sleeve (DIN 46228-1/-2/-3/-4) and 2 x 2.5 mm² stranded wire with sleeve (DIN 46228-1/-2/-3) can be connected. The wire stripping length is 10 mm, and fastening is done via plus-minus terminal screws M 3.5 with a tightening torque of 0.8 Nm. The terminals are designed as box terminals, ensuring a secure and durable connection.

Mounting and Installation
Mounting is done by securing the device to a DIN rail inside the enclosure. The width is 22.5 mm, allowing compact placement in standardized enclosures. The device dimensions are 22.5 mm (width) × 84 mm (height) × 97 mm (depth). Installation requires no additional tools other than a screwdriver for securing the wires. The terminals are designed to ensure a secure connection even under vibration, as confirmed by vibration resistance (amplitude 0.35 mm, frequency 10–55 Hz) according to IEC/EN 60068-2-6.

Advantages in Operation
The time relay offers high operational reliability with a mechanical life of 10⁸ switching operations and an electrical life of 1.5 × 10⁵ switching operations at 1 A and AC 230 V. The reset time is ≤ 100 ms, enabling a quick response after a switching operation. The permissible switching frequency is 36,000 switching operations per hour, suitable for intensive operating conditions. The operating temperature ranges from -20 °C to +60 °C, and the storage temperature is from -25 °C to +70 °C. The relative humidity is up to 95 % at 40 °C, and the operating altitude is limited to ≤ 2000 m. The enclosure protection rating is IP 40, and the terminals are IP 40, providing protection against contact and dust, but not against splashing water. The insulation test voltage is 2.5 kV for 1 minute, and the overvoltage category is III. EMC tests include static discharge (6 kV contact, 8 kV air), HF radiation (20 V/m), and fast transients (4 kV), ensuring reliability in electromagnetically disturbed environments.

Technical data
Enclosure designSwitch cabinet
Output contacts1 C/O contact
Time function(s)On-delay
Width22,5 mm
TypeBC 7930N
Variant
Contact equipping1 changeover contact
Nominal voltageAC/DC 24 V + AC 230 V
Time range15 - 300 s


Product data sheet
Datasheet for Dold 0052649, EAN: 4030641526498

Questions & answers

What is the delivery time of Dold 0052649 BC7930N.81 AC/DC24V+AC230V 15-300S time relay delayed pickup ?

The article Dold 0052649 BC7930N.81 AC/DC24V+AC230V 15-300S time relay delayed pickup is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Dold 0052649 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Dold 0052649 BC7930N.81 AC/DC24V+AC230V 15-300S time relay delayed pickup always at the best possible price. We can give you a discount of 2% on Dold 0052649 BC7930N.81 AC/DC24V+AC230V 15-300S time relay delayed pickup if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 6 pieces of Dold 0052649 BC7930N.81 AC/DC24V+AC230V 15-300S time relay delayed pickup we can offer you a price of 61,68 EUR per piece. The more you buy, the cheaper the article will be.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
