Dold 0050773 EF7666.32 AC 50/60 Hz 24 V 0.2 s–60 h time relay delayed return
|
335,33 EUR |
|||||||||||
|
( 399,04 EUR incl. VAT ) ≈ £280.67 | ≈ $368.53 plus delivery charges: 55,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 1583452 | ||||||||||
| Mfg Part No: | 0050773 | ||||||||||
| UPC/EAN: | 4030641507732 | ||||||||||
| Weight: | 0.44 kg | ||||||||||
| Type: | EF7666.32 AC50/60HZ 24V 0,2S-60H | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Dold 0050773:
Applications
This device is designed for industrial applications where precise, time-delayed switching off is required. Typical applications include controlling fans, pumps, lighting systems, or other devices that must continue operating for a certain time after the main signal is switched off. Use in automation technology, manufacturing technology, or building automation is common. The IP65 protection rating of the front makes the device suitable for environments with splashing water, for example in production halls or outdoor areas.
Functions and Equipment in Detail
The time relay features two output contacts: one delayed changeover contact and one instantaneous changeover contact. The delayed switching occurs after switching off the control signal, with the delay time being set steplessly via an adjustment pointer on an absolute scale. The repeatability accuracy is ≤ ± 0.5 % of the scale end value, with a permissible deviation of ≤ ± 1 % in the range of 3 and 6 seconds. The timing indicator allows visual monitoring of the timing process. The switching position indicator shows the current state of the contacts. The device is voltage-free safe, meaning it returns to its default state when the supply voltage is interrupted.
Technology Explained Simply
The timing process is implemented by a mechanical timing mechanism, controlled via a stepless rotary switch. The adjustment is made via six switchable time ranges, accessible from the front. The delay time can thus be set over a very wide range from 0.2 seconds to 60 hours. The response time of the contacts is less than 35 milliseconds, the release time is less than 60 milliseconds, and the reset time is under 150 milliseconds. The contact configuration consists of one delayed changeover contact and one instantaneous changeover contact, with the contact material being AgNi with a gold layer of 0.2 μm.
Compatibility and Accessories
The device is designed for use in industrial control systems and is compatible with standard control systems. It can be used in combination with other devices from the MINITIMER series, such as AA 7666, EC 7666, or EH 7666, although the respective widths and front panel areas differ. The rated voltage of AC 24 V is common for many industrial applications. The switching capacity according to AC 15 is 3 A at AC 230 V, with an electrical life of 100,000 switching operations at 3 A and AC 230 V. The mechanical life exceeds 30 million switching operations or over 15,000 operating hours.
Mounting and Installation
The device is designed for front panel mounting and is intended for a width of 72 mm. Mounting is carried out in standard control panels or enclosures. The connection terminals are designed for wiring. The delay time is adjusted via the rotary switches on the front. The switching position indicator and timing indicator facilitate commissioning and maintenance.
Advantages in Operation
The wide adjustment range from 0.2 seconds to 60 hours allows flexible adaptation to different requirements. The simple, stepless adjustment via the front reduces commissioning time. The high repeatability accuracy and voltage-free safety increase operational reliability. The IP65 protection rating of the front protects against splashing water and enables use in harsh environments. The mechanical life of over 30 million switching operations ensures long-term operation without maintenance.
| Technical data | |
| Enclosure design | Front panel mounting |
| Output contacts | 1 C/O contact |
| Time function(s) | Off-delay, with control signal |
| Width | 72 mm |
| Type | EF 7666 |
| Variant | |
| Contact equipping | 1 changeover contact delayed, 1 changeover undelayed |
| Nominal voltage | AC 24 V |
| Time range | 0,2 s - 60 h |
Questions & answers
What is the delivery time of Dold 0050773 EF7666.32 AC 50/60 Hz 24 V 0.2 s–60 h time relay delayed return ?
The article Dold 0050773 EF7666.32 AC 50/60 Hz 24 V 0.2 s–60 h time relay delayed return is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Dold 0050773 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Dold 0050773 EF7666.32 AC 50/60 Hz 24 V 0.2 s–60 h time relay delayed return always at the best possible price. We can give you a discount of 2% on Dold 0050773 EF7666.32 AC 50/60 Hz 24 V 0.2 s–60 h time relay delayed return if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 4 pieces of Dold 0050773 EF7666.32 AC 50/60 Hz 24 V 0.2 s–60 h time relay delayed return we can offer you a price of 330,30 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
