Dold 0049638 BG7925.21/002 DC24V 1-10S delay module

Your rating:
Average rating
product review for Dold 0049638 BG7925.21/002 DC24V 1-10S delay module
( 4.6 / 5 ) 13 ratings
Dold 0049638
This image may differ from the desired article.
Dold 0049638Dold 0049638
211,90 EUR
( 252,16 EUR incl. VAT )
≈ £177.36  |  ≈ $232.88
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Dold 0049638 BG7925.21/002 DC24V 1-10S delay module
Datasheet:file_download Download
Lieske Part No.:1312749
Mfg Part No: 0049638
UPC/EAN: 4030641496388
Weight:0.237 kg
Type:BG7925.21/002 DC24V 1-10S
Graduated prices net
From piecesPrice per pieces
5203,95 EUR
10196,01 EUR
15188,06 EUR
20180,12 EUR

Product information for Dold 0049638:

The Dold delay module BG7925.21/002 DC24V 1-10S is an industrial safety relay designed for implementing delayed disconnections in control systems. It is particularly used for the safe disconnection of drives, machines, or other electrical loads with an adjustable time delay between 1 and 10 seconds. The device is designed for use in safety applications and complies with the requirements of standards EN ISO 13849-1 and IEC/EN 62061, being certified up to Category 2 and Performance Level d as well as SIL 2. The operating voltage is DC 24 V, and the module is equipped with auxiliary voltage, allowing two independent time circuits to be set.

Applications
This delay module is used in industrial plants where controlled, time-delayed disconnection is required, for example, during the shutdown of conveyor belts, presses, or other machines, to ensure that moving parts come to a complete stop. It can be used in conjunction with suitable switching devices or controls in safety-critical applications, particularly in automation technology and the machine-building industry. The UL-Recognized approval highlights its suitability for use in installations complying with UL safety requirements.

Functions and Equipment in Detail
The device features contact configuration with one normally closed (NC) and one normally open (NO) contact, with a maximum contact arrangement of up to one NC and three NO contacts. The contacts are positively guided, ensuring a safe and reliable switching function. The time delay is digitally adjustable and offers high long-term stability. A switching position indicator allows visual verification of the operating status. Connection is made via removable screw terminals, enabling flexible and secure connections. Wire connection options include 2 x 1.5 mm² stranded wire with ferrule and plastic collar according to DIN 46 228-1/-2/-3/-4 or 2 x 2.5 mm² stranded wire with ferrule according to DIN 46 228-1/-2/-3.

Technology Explained Simply
The digital time stage ensures precise and reproducible time delay, unaffected by mechanical wear. The auxiliary voltage enables independent control of two time circuits, increasing flexibility when controlling different loads. The module is designed for use in safety systems, with approvals according to EN ISO 13849-1 (Category 2, PL d) and IEC/EN 62061 (SIL 2) confirming compliance with required safety standards. The thermal current is up to 5 A, defining the contact load capacity.

Compatibility and Accessories
The delay module is designed for use in combination with suitable switching devices or controls. It is part of the BG 7925 product family and can be used in systems requiring delayed disconnection with queryable safety relays. The width is 22.5 mm, enabling compact mounting in standard control panels.

Mounting and Installation
Mounting is carried out in standard control panels with a width of 22.5 mm. The removable screw terminals facilitate installation and maintenance. The connection terminals are designed for use with stranded wires according to DIN 46 228, ensuring a secure and standardized connection. Installation must comply with general safety guidelines and the manufacturer’s instructions.

Advantages in Operation
The digital time stage provides high stability and accuracy over the device’s lifetime. The positively guided contacts ensure reliable switching performance, even under load. Approvals according to EN ISO 13849-1 and IEC/EN 62061 enable use in safety-critical applications. The compact design and removable terminals simplify integration into existing systems. The switching position indicator supports maintenance and diagnostics during operation.

Technical data
1- / 2-channel1
ApprovalsUL-Recognized
Cat. / PL acc. to EN ISO 13849-12/d
ConnectionPluggable screw terminals
Output contacts max.1 NC contact, 3 NO contacts
SIL CL acc. to IEC/EN 620612
SIL acc. to IEC/EN 620612
Thermal current Ith max.5 A
Time delay max.10 s
Width22,5 mm
TypeBG 7925
Variant
Contact equipping1 NO contact, 1 NC contact
Nominal voltageDC 24 V
Time range1 - 10 s
Approvals and MarkingsTÜV
VariantWith auxiliary voltage. 2 timing circuit adjustable


Product data sheet
Datasheet for Dold 0049638, EAN: 4030641496388

Questions & answers

What is the delivery time of Dold 0049638 BG7925.21/002 DC24V 1-10S delay module ?

The article Dold 0049638 BG7925.21/002 DC24V 1-10S delay module is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Dold 0049638 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Dold 0049638 BG7925.21/002 DC24V 1-10S delay module always at the best possible price. We can give you a discount of 2% on Dold 0049638 BG7925.21/002 DC24V 1-10S delay module if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 5 pieces of Dold 0049638 BG7925.21/002 DC24V 1-10S delay module we can offer you a price of 203,95 EUR per piece. The more you buy, the cheaper the article will be.
