Dold 0049529 IK8832 AC/DC24V alarm device

Your rating:
Average rating
product review for Dold 0049529 IK8832 AC/DC24V alarm device
( 4.4 / 5 ) 21 ratings
Dold 0049529
This image may differ from the desired article.
Dold 0049529Dold 0049529
58,85 EUR
( 70,03 EUR incl. VAT )
≈ £49.26  |  ≈ $64.68
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Dold 0049529 IK8832 AC/DC24V alarm device
Datasheet:file_download Download
Lieske Part No.:111567
Mfg Part No: 0049529
UPC/EAN: 4030641495299
Weight:0.063 kg
Type:IK8832AC/DC24V
Graduated prices net
From piecesPrice per pieces
657,97 EUR
1257,08 EUR
2456,20 EUR
3655,32 EUR

Product information for Dold 0049529:

The article is an alarm indicator from manufacturer Dold, type IK8832AC/DC24V, used for acoustic signaling of faults or limit value exceedances in industrial and installation applications. The device generates a continuous tone with fixed pitch when supply voltage is applied and is designed for mounting on a DIN rail. The rated voltage is AC/DC 24 V, with an operating voltage range between 0.8 and 1.1 times the rated voltage. The signal frequency is fixed at 4.5 kHz, and the sound level is approximately 80 dB (A) at a distance of 15 cm. The width of 17.5 mm allows for compact installation in enclosures and distribution boxes.

Applications
The alarm indicator is designed for use in industrial control systems, measuring relay installations, and distributors, where acoustic alerts are required for errors, overloads, or other critical conditions. It is particularly suitable for applications in single- and multi-family homes as well as in technical installations where visual signaling alone is insufficient. Typical uses include monitoring of temperature, pressure, or current limit values.

Functions and Equipment in Detail
The device operates in continuous operation and is designed for an operating temperature range of -20 °C to +60 °C. The operating altitude is limited to a maximum of 2000 m above sea level. The signal frequency is not adjustable but is fixed at 4.5 kHz, ensuring clear and unambiguous acoustic perception. The terminal connections are designed for conductor cross-sections of 2 x 2.5 mm² solid or 2 x 1.5 mm² stranded wire with ferrule according to DIN 46228. The terminals are equipped with self-lifting connection washers, enabling secure and quick connections. The tightening torque is 0.8 Nm.

Technology Explained Simply
The alarm indicator uses an electronic circuit that activates a piezoelectric or electromagnetic speaker when supply voltage is applied, generating the signal tone. DIN rail mounting is achieved via an integrated quick-fastening system, enabling installation in standard enclosures according to IEC/EN 60715. The housing is made of thermoplastic with V0 behavior according to UL Subject 94, ensuring a high flame protection class and safe use in electrical installations. The protection rating IP 40 for the housing and IP 20 for the terminals protects against contact with moving parts and ingress of solid foreign objects larger than 1 mm, but does not protect against water or dust.

Compatibility and Accessories
The alarm indicator is available in I form factor, featuring a depth of 61 mm and terminals located at the bottom. This form factor is intended for installation and industrial distributors according to DIN 43 880. Alternatively, an S form factor is available with a depth of 100 mm and terminals located at the top, suitable for enclosures with mounting plates and cable ducts. The devices are available in various voltage variants, with the variant described here designed for AC/DC 24 V. Another variant, the IK8832/100, offers a switchable tone frequency (2.4 / 4.8 kHz), but this is not part of this article.

Mounting and Installation
Mounting is done by simply clipping onto a DIN rail. The terminals are designed for connection with solid or stranded conductors, with the use of ferrules recommended. The terminals are flat and allow for secure fastening. The devices are designed for use in enclosures and distributors, with mounting height and depth to meet respective requirements. Vibration resistance is ensured according to IEC/EN 60068-2-6 with an amplitude of 0.35 mm and a frequency range of 10 to 55 Hz.

Advantages in Operation
The alarm indicator provides reliable and clear acoustic signaling, audible even in noisy environments. The fixed tone frequency of 4.5 kHz ensures unambiguous signal identification. The compact form factor with 17.5 mm width enables efficient space utilization in enclosures. DIN rail mounting and standardized terminals simplify installation and maintenance. EMC coverage according to IEC/EN 61000-4-2 to -4-6 ensures robust operation in electromagnetically demanding environments. Radio frequency interference suppression complies with emission limit class B according to EN 55011, ensuring compliance with legal requirements for electromagnetic compatibility.

Technical data
Width17,5 mm
TypeIK 8832
For top hat rail mountingYes
Variant
Nominal voltageAC/DC 24 V
VariantPermanent sound. Pitch fixed


Product data sheet
Datasheet for Dold 0049529, EAN: 4030641495299

Questions & answers

What is the delivery time of Dold 0049529 IK8832 AC/DC24V alarm device ?

The article Dold 0049529 IK8832 AC/DC24V alarm device is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Dold 0049529 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Dold 0049529 IK8832 AC/DC24V alarm device always at the best possible price. We can give you a discount of 2% on Dold 0049529 IK8832 AC/DC24V alarm device if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 6 pieces of Dold 0049529 IK8832 AC/DC24V alarm device we can offer you a price of 57,97 EUR per piece. The more you buy, the cheaper the article will be.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
