Dold 0041907 IK8701.01/006 DC24V switching relay

Your rating:
Average rating
product review for Dold 0041907 IK8701.01/006 DC24V switching relay
( 4.4 / 5 ) 5 ratings
Dold 0041907
This image may differ from the desired article.
51,71 EUR
( 61,53 EUR incl. VAT )
≈ £43.28  |  ≈ $56.83
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Dold 0041907 IK8701.01/006 DC24V switching relay
Datasheet:file_download Download
Lieske Part No.:1312828
Mfg Part No: 0041907
UPC/EAN: 4030641419073
Weight:0.11 kg
Type:IK8701.01/006 DC24V
Graduated prices net
From piecesPrice per pieces
650,93 EUR
1250,16 EUR
2449,38 EUR
3648,61 EUR

Product information for Dold 0041907:

The Dold switching relay IK8701.01/006 DC24V is an industrial relay for use in control and automation technology. It serves as an input or output coupling relay, for example, for actuating PLC systems or controlling PLC-controlled loads. The device is specifically designed for operation with direct voltage and features a rated voltage of DC 24 V. The contact configuration includes 1 normally open contact, with a maximum contact arrangement of up to 2 changeover contacts possible. The width is 17.5 mm, making it suitable for use in standard installation distributors. The housing design is implemented as an installation distributor, enabling easy mounting in enclosures.

Applications
This relay is designed for use with large inductive direct voltage loads, for example, at DC 220 V with a time constant of 30 ms (L/R = 30 ms). The contact gap is 6 mm, ensuring reliable switching performance under high loads. It is particularly suitable for applications requiring high mechanical and electrical load capacity, such as in industrial automation or for controlling motors and other inductive loads.

Functions and Equipment in Detail
The device features a manual actuation button for contacts, which also serves as a switch position indicator. When energized, the button is inserted; when de-energized, it flushes with the front edge. This function allows for manual testing of the switching function and visual monitoring of the switch state. The contacts are actuated via a toggle armature with a plunger; when the excitation voltage is switched off, the armature is returned to its rest position by a spring.

Technology Explained Simply
The relay coil is equipped with protective circuitry at the input, protecting against unwanted voltage spikes. In DC devices, a freewheeling diode is integrated, serving as reverse polarity protection and suppressing switching spikes. The connection polarity is via A2+, ensuring secure power supply. The thermal current Ith max. is 16 A, describing the relay's load capacity under continuous operation. The contacts are designed for industrial environments and comply with the standard EN 60947-5-1, which defines requirements for control devices.

Compatibility and Accessories
The relay is suitable for actuation with 2-wire initiators, with an allowable residual current ≤ 3 mA. It can also be operated with up to six neon lamps (each 0.5 mA) in parallel with the network button. The contact arrangement is flexibly designed, with the variant featuring a 6 mm contact gap specifically designed for inductive loads. The devices are available in various versions, with the described version optimized for DC 24 V and large inductive loads.

Mounting and Installation
The relay is mounted in standard installation distributors, with the width of 17.5 mm enabling compact placement. The connection terminals are clearly labeled (A1/A2 for control signal, 11/12/14 etc. for load contacts), ensuring unambiguous wiring. Mounting typically occurs in enclosures or distributors, with mechanical stability and switching function ensured by the design.

Advantages in Operation
The relay offers high reliability when switching large inductive loads, supported by the 6 mm contact gap and integrated protective circuitry. The manual actuation button enables easy diagnosis and testing during operation. Compliance with EN 60947-5-1 ensures adherence to safety and performance standards. The installation distributor design ensures easy integration into existing control systems.

Technical data
Enclosure designDistribution board
Output contacts max.2 C/O contacts
Thermal current Ith max.16 A
Width17,5 mm
TypeIK 8701
Initiator triggeringYes
Suppressor circuit on the coil inputYes
Variant
Contact equipping1 NO contact
Nominal voltageDC 24 V
Variant6 mm contact opening, for switching large inductive direct current voltage loads


Product data sheet
Datasheet for Dold 0041907, EAN: 4030641419073
