D-Link DGS-1210-20/E Switch 16xGBit/4xSFP 48,3 cm ( 19 inch ) Managed
|
144,06 EUR |
|
|
( 171,43 EUR incl. VAT ) ≈ £121.01 | ≈ $161.64 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 8 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1971746 |
| Mfg Part No: | DGS-1210-20/E |
| UPC/EAN: | 0790069467745 |
| Weight: | 3.317 kg |
| Type: | DGS-1210-20/E |
Product information for D-Link DGS-1210-20/E:
The Web Smart Managed Gigabit Switch DGS-1210 supports numerous features that are normally only found in high-end switches. It ensures maximum control, service and security, but without the complexity of an enterprise switch. Due to the very low administration effort, it is ideal for use in small and medium-sized companies.
Highlights
- 16 x 10/100/1000BASE-T port
- 4 x 100/1000 Mbit/s combo port
- VLAN, QoS, fanless
- Capacity: 40 Gbit/s
- Thermal conduction: 44.41 BTU/hr
- Switch
- ear -Category (ElektroG): relevant, Category 6: small IT and telecommunications technology devices, small IT and telecommunications technology devices B2C
- Switch type: Access
- Switching capacity: 40 GBit/s (Gbps)
- WEEE: 10490255
- Number of copper ports total: 16
- Bandwidth: 10/100/1000 MBit/s
- Main port type: Copper
- Number of RJ45 ports (1G): 16
- Number (1G) ports combo: 4
- Number of combo ports Total: 4
- Switch manageable: Yes
- Mounting type: 48,3 cm ( 19 inch ) rack mount
- IGMP
- Power supply: integrated
- Color: Black, Gray
- Height: 44 mm
- Length/depth: 180 mm
- Width: 280 mm
- D-Link DGS-1210-20 20-Port Layer2 Smart Managed Gigabit Switch
Product type
Specifications
Shipping
Connections
Functions
Power supply
Basic features
Scope of delivery
| Data transmission | |
| Switching capacity | 40 Gbit/s |
| Forwarding rate | 77.4 Mpps |
| MAC address table | 8000 entries |
| Jumbo frames | 10000 |
| Packet buffer memory | 4.1 MB |
| Store-and-forward | |
| Jumbo frames support | |
| Design | |
| Form factor | 1U |
| Product colour | Black |
| Rack mounting | |
| Stackable | |
| LED indicators | |
| Management features | |
| Switch type | Managed |
| Switch layer | L2 |
| MIB support | Y |
| Quality of Service (QoS) support | |
| Web-based management | |
| ARP inspection | |
| Configuring Location Settings (CLI) | |
| System event log | |
| Multicast features | |
| Multicast support | |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Number of VLANs | 256 |
| Port mirroring | |
| Full duplex | |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Auto MDI/MDI-X | |
| Spanning tree protocol | |
| Head-of-line (HOL) blocking | |
| Auto-negotiation | |
| VLAN support | |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 44.62 BTU/h |
| Performance | |
| Memory type | DDR3-SDRAM |
| Internal memory | 256 MB |
| Flash memory | 32 MB |
| Mean time between failures (MTBF) | 1087100 h |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 4 |
| Power connector | AC-in jack |
| Power | |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 13.08 W |
| Power supply included | |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Security | |
| DHCP features | DHCP client, DHCP server |
| Access Control List (ACL) | |
| IGMP snooping | |
| MAC address filtering | |
| Loop protection | |
| Weight & dimensions | |
| Width | 280 mm |
| Depth | 180 mm |
| Height | 44 mm |
| Weight | 1.75 kg |
Questions & answers
What is the delivery time of D-Link DGS-1210-20/E Switch 16xGBit/4xSFP 48,3 cm ( 19 inch ) Managed?
The article D-Link DGS-1210-20/E Switch 16xGBit/4xSFP 48,3 cm ( 19 inch ) Managed is currently in stock
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of D-Link DGS-1210-20/E to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you D-Link DGS-1210-20/E Switch 16xGBit/4xSFP 48,3 cm ( 19 inch ) Managed always at the best possible price. We can give you a discount of 2% on D-Link DGS-1210-20/E Switch 16xGBit/4xSFP 48,3 cm ( 19 inch ) Managed if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
