D-Link DGS-1100-24PV2 24-Port PoE Gigabit Smart Switch
|
259,45 EUR |
|||||||||||
|
( 308,75 EUR incl. VAT ) ≈ £217.94 | ≈ $291.10 plus delivery charges: 53,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline | |||||||||||
| In Stock: >25 pieces | |||||||||||
| End-Of-Life: | 06. Sep 2026 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Datasheet: | file_download Download | ||||||||||
| Lieske Part No.: | 1971316 | ||||||||||
| Mfg Part No: | DGS-1100-24PV2/E | ||||||||||
| UPC/EAN: | 0790069467837 | ||||||||||
| Weight: | 3.1333 kg | ||||||||||
| Type: | CPNT | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for D-Link DGS-1100-24PV2/E:
The DGS-1100 Smart Switch Series is a cost-effective solution for environments that require simple network management. Layer 2 functions such as VLANs, Spanning Tree Protocol (STP) and Link Aggregation (static) can be easily controlled via the user-friendly web interface of the DGS-1100 switches. With strong security features such as IGMP snooping, static MAC addresses and storm control, the DGS-1100 series is versatile in environments that require quickly and easily deployable solutions without additional complexity.
Highlights
- 24x Gigabit Ethernet port
- Port 1 to 12 with PoE support (IEEE 802.3af/802.3at)
- Switch capacity: 48 Gbit/s
- PoE budget: 100 watts (up to 30 watts per port)
- Simple Layer 2 -Administration
- Web-based user interface
- Switch
- ear category (ElektroG): relevant, Category 6: small IT and telecommunications technology devices, Small IT and telecommunications technology devices B2C
- Switch type: Access
- Switching capacity: 48 GBit/s (Gbps)
- WEEE: 10490255
- Total number of copper ports: 24
- Total number of PoE ports: 12
- Bandwidth: 10/100/1000 MBit/s
- PoE standard: PoE - 802.3 af, PoE+ - 802.3at
- PoE budget: 100 W
- Main port type: Copper
- Number of PoE+ (af/at) ports: 12
- Number of RJ45 ports (1G): 24
- Switch manageable: Yes
- Mounting type: 48,3 cm ( 19 inch ) rack mount
- IGMP
- Power supply: integrated
- Color: silver, black
- Height: 44 mm
- Length/depth: 230 mm
- Width: 280 mm
- Weight: 2.15 kg
- D-Link DGS-1100-24PV2 24 -Port PoE Gigabit Smart Switch
Product type
Specifications
Shipping
Connections
Functions
Power supply
Basic features
Scope of delivery
| Certificates | |
| Certification | EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC |
| Data transmission | |
| Switching capacity | 48 Gbit/s |
| Forwarding rate | 35.71 Mpps |
| MAC address table | 8000 entries |
| Number of queues | 4 |
| Jumbo frames | 9216 |
| Packet buffer memory | 4.1 MB |
| Store-and-forward | |
| Jumbo frames support | |
| Design | |
| Product colour | Black |
| Rack mounting | |
| LED indicators | |
| Management features | |
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | |
| Web-based management | |
| System event log | |
| Multicast features | |
| Multicast support | |
| Network | |
| Networking standards | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Copper ethernet cabling technology | 10BASE-T, 10BASE-TX, 1000BASE-T |
| Virtual LAN features | Port-based VLAN, Voice VLAN |
| Number of VLANs | 128 |
| 10G support | |
| Port mirroring | |
| Full duplex | |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Rate limiting | |
| Auto MDI/MDI-X | |
| Spanning tree protocol | |
| Head-of-line (HOL) blocking | |
| Auto-negotiation | |
| VLAN support | |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 2000 m |
| Heat dissipation | 107.5 BTU/h |
| Performance | |
| Processor frequency | 125 MHz |
| Memory type | DRAM |
| Flash memory | 16 MB |
| Noise level | 0 dB |
| Mean time between failures (MTBF) | 255003 h |
| Built-in processor | |
| Fanless | |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power | |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 19.5 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 12 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 100 W |
| Power over Ethernet (PoE) | |
| Security | |
| DHCP features | DHCP client |
| Security algorithms | SNMP, SSL/TLS |
| Queue scheduling algorithms | SPQ, Weighted Round Robin (WRR) |
| IGMP snooping | |
| Weight & dimensions | |
| Width | 280 mm |
| Depth | 230 mm |
| Height | 44 mm |
| Weight | 2.2 kg |
Please note...
We have listed this article as 'end-of-life', which means that it will only be sold until it is completely sold out ! Please mind that we cannot guarantee you, you will receive the article, although it may be betokened as available. You can find the date from when the article was marked end-of-life to the top.
Questions & answers
What is the delivery time of D-Link DGS-1100-24PV2 24-Port PoE Gigabit Smart Switch?
The article D-Link DGS-1100-24PV2 24-Port PoE Gigabit Smart Switch is currently in stock
According to our experience the article is ready for dispatch within 6 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of D-Link DGS-1100-24PV2/E to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you D-Link DGS-1100-24PV2 24-Port PoE Gigabit Smart Switch always at the best possible price. We can give you a discount of 2% on D-Link DGS-1100-24PV2 24-Port PoE Gigabit Smart Switch if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 4 pieces of D-Link DGS-1100-24PV2 24-Port PoE Gigabit Smart Switch we can offer you a price of 255,56 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
