Chauvin Arnoux P01102198 Transponder (100 pcs) content_copy

The CA 6163 from Chauvin Arnoux is a professional installation tester for electrical safety testing of devices, machines and enclosures. It is particularly used for conformity testing within final inspection, recurring tests, as well as maintenance and repair work. The device is designed for use in industrial electrical engineering, by electricians, maintenance companies, service providers and testing facilities. It enables comprehensive testing according to applicable standards and norms to ensure the safety of electrical installations.

Applications
The CA 6163 is used in various industries, including the manufacturing of electrical devices and equipment, testing of low-voltage enclosures, maintenance of industrial machines, and technical training. It is particularly suitable for testing electrical machines and enclosures to verify conformity with standards such as IEC/EN 60204-1, IEC/EN 61439-1 and IEC/EN 60335-1. The devices are also designed for testing RCD protective devices (FI protective devices) in ramp and impulse mode.

Functions and Equipment in Detail
The device features a touch colour display with a resolution of 800 x 480 pixels and a screen size of 5 inches, which can also be operated with gloves. The multilingual user interface provides assistance screens with text, symbols and images to guide the operator through the testing processes. Four express command buttons allow quick access to functions such as printing test results, accessing help, returning to the main screen or the previous menu. The integrated software supports storage of up to 100,000 tests and enables data transfer via WLAN or USB connection to a PC for analysis and reporting.

Technology Explained Simply
The CA 6163 offers a variety of measurement functions, including continuity tests in 2- or 4-wire measurement with test currents of 0.1 A, 0.2 A, 10 A and 25 A. Insulation testing is performed with test voltages of 100 V, 250 V, 500 V and 1,000 V, with a maximum measurement up to 50 GΩ. Loop impedance (Zs) can be measured up to 2,000 Ω, with the display range for short-circuit current (Ik) reaching up to 20 kA. Leakage current measurement is performed directly at the socket (30 mA) or via a current clamp (40 A), with an accuracy of ±2 % L. Testing of RCD protective devices is carried out in ramp and impulse mode with various settings such as x 0.5, x 1, x 2, x 4, x 5, x 10 (DC) IΔ;n. Discharge time is also measured to ensure that the test object is safely discharged after testing.

Compatibility and Accessories
The device is equipped with various interfaces, including USB-B, two USB-A ports, WLAN, as well as connections for barcode scanners, RFID scanners, label printers, START/STOP pedals, DOOR OPEN, HT pistol trigger and warning lamps. Suitable accessories include Kelvin crocodile clips, test probes, cables, power cable, HV test pistols, CEE adapters, crocodile clips CAT IV-1000 V, test probes CAT IV and CAT III 1000 V, and a transport bag. The RFID labels (100 pieces) are intended for identification and documentation of tests.

Mounting and Installation
The CA 6163 is delivered in a yellow construction case and is designed for use in industrial environments. Power supply is via 230 VAC ±10 %. Operating temperature ranges from 0 °C to +45 °C, and storage temperature ranges from -30 °C to +60 °C. The device is equipped with a protection rating of IP 40 (open) and IP 40 (closed), as well as a mechanical protection rating of IK 08, ensuring high robustness against dust, water and mechanical impacts.

Advantages in Operation
The CA 6163 offers high measurement accuracy and reliability when testing electrical installations. Integrated functions such as automatic discharge, two-hand operation and optical indication of high voltage increase safety during testing. The ability to automatically sequence tests and print Pass/Fail stickers directly accelerates the workflow. Communication options via WLAN and USB enable easy data transfer and analysis. The devices are suitable for use in various conformity testing applications and support documentation and reporting via PC software.

Safety and Standards Compliance
The device complies with the safety requirements of standards IEC 61010-1, IEC 61010-2-030, IEC 61010-2-034 and IEC 61010-2-032. It is designed for categories 300 V CAT II, 300 V CAT III and 600 V CAT III. Testing is carried out in accordance with standards IEC 61557-1, -2, -3, -4, -6, -7, -10, -13, -14, -16 (partially). High-voltage tests comply with the requirements of standards IEC/EN 61010-031 and IEC/EN 61180, where the test trigger must be pressed for a certain period to ensure safe operation. Automatic discharge of the test object after testing protects the operator from dangerous voltages.

Eigenschaften
AC / AC ramp	40 - 5 350 V
Resolution / accuracy	10 V / ±1 % L
Maximum current	200 mA
Measurement of I range / accuracy	100 mA / 200 mA ±2 % L
Test voltage	100 V / 250 V / 500 V / 1 000 V
Inductance range / resolution / accuracy	15 mH / ±10 % L
Impulse test	x 0,5; x 1; x 2; x 4; x 5; x 10 (DC) IΔ;n
Isolation current resolution / accuracy	0,1 mA; -0% +(7% L + 2 mA)
Voltage and frequency of installation	190,0 - 440,0 V; 45-55 Hz
Measurement range / accuracy	40 A / ±2,5 % L
Dimensions / weight	407 x 341 x 205 mm; 16 kg

---
