BlackBox VCC-SD-HD-3 2 CHAN HD + 1 CHAN SD FULL HEIGHT

Radian Video Wall Controller Capture Card - HDMI 2.0 4K60 4:4:4, HDCP 2.2, 2-Channel

Capture two channels of HDMI 2.0 video input with HDCP 2.2 support at up to 4K60 with full 4:4:4 color sampling for use on your video wall.

This capture card is ideal for Radian Video Wall Controller solutions, offering two HDMI 2.0 capture channels with HDCP 2.2 support at resolutions up to 4K60 with full 4:4:4 color sampling, ensuring high-quality and vibrant video display. The card utilizes a PCIe Gen3 x8 form factor, delivering 6 Gbps of capture bandwidth and a complete 10-bit processing pipeline along with 2GB of frame buffer memory.

With built-in Windows® WDM support, the card is suitable for streaming applications, enabling captured video to be compressed and streamed via Windows Media Encoder, with playback available through Windows® Media Player. This capture card is compatible with any application using Windows® DirectShow technology.

DirectShow drivers for WDM Streaming support applications such as Microsoft Media Encoder®, VLC, VirtualDub, and other DirectShow-compatible software for video encoding, recording, and streaming.

Warranty: 1-Year Double Diamond™ (Standard)

Specifications:

• Form Factor: PCIe Gen3 x8
• Channels: 2
• Frame Buffer Memory: 2GB
• Operating Temperature: 32 to 95° F (0 to 35° C)
• Power Consumption: 1.7A @ 12V; 0.1A @ 3.3V; Max Power 21W
• Resolution: 4K60 4:4:4
• Storage Temperature: -4 to +158° F (-20 to +70° C)
• Connectors: 2x HDMI
• Dimensions: 4.3 in. W x 7.67 in. D (110 x 195 mm), including heat sink
• TAA Compliant: Yeser Memory: 2GB
• Operating Temperature: 32 to 95° F (0 to 35° C)
• Power Consumption: 1.7A @ 12V; 0.1A @ 3.3V; Max Power 21W
• Resolution: 4K60 4:4:4
• Storage Temperature: -4 to +158° F (-20 to +70° C)
• Connectors: 2x HDMI
• Dimensions: 4.3 in. W x 7.67 in. D (110 x 195 mm), including heat sink
• TAA Compliant: Yes
