BlackBox MDS968C-RP-R2 DSL RACK SOLUTION WITH LOCAL/REMOTE POWER SOURCE

Etherlink IV

Build a metro network with an incredible 60-Mbps speed.

Transmits Ethernet data over 2-, 4-, or 8-wire telephone lines.
Transparent connection.
Data rates: 15 Mbps over 2 wires, 30 Mbps over 4 wires, 60 Mbps over 8 wires.
Supports point-to-point, point-to-multipoint, and multidrop applications.
SNMP management with or without IP (802.3ah).
Integrated Ethernet switch.
Built-in surge protection on the DSL side.
VLAN 802.1q support for network scalability.

### Product Description

EtherLink IV delivers DSL Ethernet extension with high speeds and long-range capabilities, perfect for metro networks. Using G.SHDSL technology, this modem achieves 15 Mbps per copper pair over distances that traditional DSL modems cannot reach. With up to 8 wires, EtherLink IV supports data rates up to 60 Mbps over distances of up to 2,500 meters.

### Flexible Applications

EtherLink IV supports point-to-point connections as well as more complex point-to-multipoint and multidrop topologies. A 2-wire model can be used for simple routes, while the 4- and 8-wire versions are ideal for central sites connecting multiple locations.

### Benefits Over Fiber Optics

While fiber offers high speeds, installation costs can be high. EtherLink IV utilizes readily available copper lines, saving installation expenses while providing sufficient bandwidth for broadband applications like VoIP, video-on-demand, and internet access.

### Technical Specifications

Connections
MDS962AE-10BT-R2:
- (2) RJ45 Ethernet 10/100BaseTX
- (1) DB9 socket (USB) for monitoring and configuration
- (1) RJ45 2-wire (Pins 4 & 5) for DSL route

MDS964AE-10BT-R2:

- (2) RJ45 Ethernet 10/100BaseTX
- (1) DB9 socket (USB) for monitoring and configuration
- (1) RJ45 4-wire (Pins 3 & 6, 4 & 5) for DSL route

MDS968AE-10BT-R2:

- (4) RJ45 Ethernet 10/100BaseTX
- (1) DB9 socket (USB) for monitoring and configuration
- (2) RJ45 8-wire for DSL route

Standards

• 802.3ah, G.SHDSL.BIS, G.SHDSL, 802.1q, 802.3, 802.3u, ITU-T K20/K21, IEC 1000-4-5 Class 2

Management

• VT100 (via RS-232/v.24), Telnet, HTTP (web-based), SNMP, VLAN 802.1q

Power Supply

• 48V DC, 1A, includes external power adapter (100-240V AC)

Dimensions

• 220 mm (Width) x 160 mm (Length) x 40 mm (Height)

Operating Temperature

• -30 to +75 ° Celsius
