BlackBox EMD2000-PSU EMERALD 5VDC SPARE PSU

Emerald® SE DVI IP-based KVM Extender - Single-Head/Dual-Head, V-USB 2.0, Audio, Virtual Machine Access:

The Emerald® SE DVI IP-based KVM Extender provides full HD KVM extension and switching for physical and virtual machines over IP-based CATx KVM connections. Offering virtually lossless Full HD DVI video up to 1920 x 1200, USB HID, Transparent USB (2.0), and audio, the extender supports both physical and virtual desktop connections.

Features:

• Next-generation KVM extension and matrix switching for physical and virtual servers
• Full HD DVI video up to 1920 x 1200
• Low IP bandwidth requirements: Less than 40 Mbps for 1080p video
• Supports USB HID, Transparent USB (2.0), and stereo audio
• Point-to-point extension up to 100 meters over CATx
• Allows multiple users to simultaneously access a single source
• Compatible with KVM systems like DKM®, Agility®, Boxilla®, Emerald® 4K, and ControlBridge
• Easy scalability and high reliability
• Warranty: 2-Year Double Diamond™ (Standard)

About IP-based Emerald® KVM:
Emerald® is a high-performance KVM extension and matrix switching solution for enterprises, delivering pixel-perfect video in Full HD or 4K/60 over IP networks. The flexible and scalable system supports both physical and virtual servers, enabling smooth access across buildings and sites.

System Design:

Emerald includes transmitters connecting computers or virtual machines and receivers connecting user consoles. Use Emerald SE for point-to-point extension over CATx or integrate multiple units into a KVM matrix switching system.

Network Requirements:

Emerald requires a standard Gigabit Ethernet network for HD video. Depending on the number of endpoints, a 10-Gigabit switch may be needed. The network infrastructure can be built based on IEEE 802.3 standards.

Technical Data:

• Max Resolution: Full HD DVI-D up to 1920 x 1200
• Bandwidth: < 40 Mbps for 1080p video
• Connectors:
- Transmitter EMD2000SE-T: 1x DVI, 1x USB Type B, 1x RJ-45, 2x 3.5mm audio, 1x power jack
- Receiver EMD2000SE-R: 1x DVI, 4x USB Type A, 1x RJ-45, 2x 3.5mm audio, 1x power jack
- Transmitter EMD2002SE-T: 2x DVI, 1x USB Type B, 1x RJ-45, 2x 3.5mm audio, 1x power jack
- Receiver EMD2002SE-R: 2x DVI, 4x USB Type A, 1x RJ-45, 2x 3.5mm audio, 1x power jack

• Distance:
- Direct connection: Up to 100 m over CATx cable
- Over network: Increased range using network switches

• Power Supply: 100–240 VAC, external power supply, 6.5 W consumption
• Dimensions: 13.7 x 15.4 x 3.4 cm
• Weight: 0.54 kg
• Operating Temperature: 0 to 40°C
• Supported OS: Windows, Linux, Mac OS
• TAA Compliant: Yes
