Emerald® USB 2.0 Switchable Extender – LAN, 4 Port:

The Emerald® USB 2.0 Switchable Extender allows switching between high-speed USB 2.0 devices over an IP network. It supports full-speed USB 2.0 up to 480 Mbps and enhances collaboration with simultaneous USB sharing. The extender can be connected to an Emerald KVM system for automatic switching when the target changes. Featuring four USB ports, it supports various USB devices, including USB hubs.

Features:

• Switch between high-speed USB 2.0 devices over an IP network
• Supports full-speed USB 2.0 with transfer rates up to 480 Mbps
• Four USB ports supporting USB devices, including hubs
• Enhanced collaboration with simultaneous USB sharing
• Integrates with Emerald KVM systems for automatic switching
• Warranty: 1-Year Double Diamond™ (Standard)

The extender expands USB 2.0 connections up to 100 meters over CATx or Ethernet LAN and is ideal for use in industrial control, factory floors, classrooms, and meeting rooms. It supplies up to 600 mA to downstream USB devices and is compatible with USB 1.1 and USB 2.0 devices.

Technical Data:

• Certifications: FCC (Class B), CE (Class B), RoHS2 (CE)
• Distance: Up to 100 m over CAT5e/6/7 cables for direct or network connections
• Connectors:
- Local Unit: 1x USB Type B, 1x RJ-45 Link
- Remote Unit: 4x USB Type A, 1x RJ-45 Link

• Power Supply:
- Local Unit: Powered via USB interface
- Remote Unit: 24 VDC, 1 A power supply (included)
- Available power for USB devices at the remote unit: Up to 2.4 A total, 600 mA per USB port simultaneously, max. 1 A per port if two or fewer ports are in use
- Power consumption: Local unit: max. 200 mA

• Operating Temperature: 0 to 50 °C, Storage Temperature: -20 to +70 °C
• Relative Humidity: 20 to 80%, non-condensing
• Dimensions: 9.9 x 7.6 x 2.5 cm (H x W x D)
• Housing: Black anodized aluminum
