BlackBox AVSP-HDMI1X4 1X4 HDMI Splitter with Audio

HDMI Splitter with Audio:

User-friendly and affordable HDMI video source duplication to up to eight HDMI displays.

Distributes one HDMI signal to up to eight outputs simultaneously.
Accurate, reliable digital video reproduction without distortion or delay.
Audio support.
Handles HDCP-protected content.
Blu-ray® ready for high-definition displays.
Supports EDID from the display for optimal video performance.
Resolutions: UXGA, WUXGA, or Full HD 1080p.
4- and 8-port models can be rack-mounted in a 48,3 cm ( 19 inch ) cabinet.

Distribute HDMI video plus audio from a satellite receiver, set-top box, PC, or another HDMI source to multiple digital displays. The HDMI splitters with audio show the content from one HDMI source simultaneously on two, four, or eight displays without quality loss. Connect the source and displays to the splitter with HDMI cables up to 5 meters long, power on, and the system is ready. You can also chain multiple splitters together if you need to connect more screens.

Video:

The HDMI splitters deliver sharp, clear images at resolutions up to UXGA (1600 x 1200), WUXGA (1920 x 1200), or Full HD 1080p (1920 x 1080). Distribute HD video and multichannel audio from sources like Blu-ray or DVD players. The splitters provide high-bandwidth transmission, allowing large amounts of data to be processed quickly for the best image quality on the screens.

Audio:

Audio is transmitted via the HDMI digital ports. Additionally, each channel has a 3.5-mm audio jack for analog audio output, which is ideal for Digital Signage and similar applications using high-quality speakers or Hi-Fi audio receivers.

Installation:

The HDMI splitters are easy to install and operate as they require no software installation or interface cards. LEDs clearly indicate activity for each port. If the input signal is lost, the splitters automatically switch to power-saving mode.

Applications:

The splitters are ideal for AV distribution in shopping malls, educational institutions, and corporate information systems. For connecting DVI displays, simply use a DVI/HDMI adapter.

Specifications:

Maximum Resolutions:
Full HD 1080p (1920 x 1080),
VGA (640 x 480),
SXGA (1280 x 1024),
UXGA (1600 x 1200),
WUXGA (1920 x 1200).

Maximum Cable Length:

5 meters.

Connections:

Input: (1) HDMI socket, (1) 3.5-mm audio jack.
Outputs:
AVSP-HDMI1X2: (2) HDMI sockets, (2) 3.5-mm audio jacks.
AVSP-HDMI1X4: (4) HDMI sockets, (4) 3.5-mm audio jacks.
AVSP-HDMI1X8: (8) HDMI sockets, (8) 3.5-mm audio jacks.

Power Supply:

Input: 100–240 V AC, 50/60 Hz, Autosensing.
Output: 9–12 V DC.
Consumption: AVSP-HDMI1X2: 2.8 W, AVSP-HDMI1X4: 4.1 W, AVSP-HDMI1X8: 10.2 W.

Dimensions:

AVSP-HDMI1X2: 2 H x 17.8 W x 8.6 D cm.
AVSP-HDMI1X4: 1 U, 4.5 H x 22.1 W x 13.7 D cm.
AVSP-HDMI1X8: 1 U, 4.5 H x 44 W x 18 D cm.

48,3 cm ( 19 inch ) Rack Mounting:
AVSP-HDMI1X2: no.
AVSP-HDMI1X4: yes, order AVSP-RMK brackets separately.
AVSP-HDMI1X8: yes, mounting brackets included.

Note:

The quality of the output signal largely depends on the video source, HDMI cab
