BlackBox ACX160-R2 SERVSWITCH DKM FX 160 W/CTRL CARD+PWR SUPPLY R2

Product Description:

The CATx Compact DKM Extender Kit allows the extension of high-resolution digital video, USB, audio, and serial data over distances of up to 140 meters. This KVM extender system transmits pixel-perfect video quality up to 2048 x 1152 at 60Hz and offers 24-bit color depth. It features USB-HID interfaces for keyboard and mouse control with true USB emulation, supporting advanced functions. The extender is available with both VGA and DVI-D inputs and offers numerous options for audio, serial data, and USB 2.0.

Ideal for applications where users need to separate their KVM console from the computer, such as in control rooms, industrial environments, retail, or POS systems, it supports resolutions up to 2048 x 1152 and provides excellent DVI-D video quality over long distances. Optional rackmount and DIN rail mounting make it suitable for industrial installations as well.

Technical Data:

• Point-to-point extension up to 140 m
• Video quality:
- Resolution up to 2048 x 1152 at 60Hz
- 24-bit color depth
- Supports interlaced video (e.g., 1080i)

• Transmission:
- CAT5e/6/7 cables for distances up to 140 m
- Fiber optic models for Multimode (1,000 m) and Singlemode (up to 10 km)

• USB-HID support:
- 2 or 4 USB-HID ports
- Full support for USB keyboards and mice

• USB 2.0:
- Highspeed USB up to 480 Mbps (model ACX1K13-C)
- 36 Mbps USB 2.0 for Single-Link DVI-D (model ACX1K14-C)

• Serial interface and audio:
- RS232/V.24 transmission up to 19.2 Kbps
- Analog and digital audio transmission

• Supported video formats:
- DVI-D and VGA
- Scalable VGA up to 1920 x 1200

• Local monitoring via optional splitter cable
• Rack and DIN rail mounting options available

Connections — Transmitter:

• All models:
- (1) DVI-I, (1) USB Type B, (1) RJ45 CATx, (1) miniUSB Type B (for Flash upgrades), (1) Power input

• Model ACX1T-11V-C:
- Additional DVI-I for VGA or DVI-D, IR sensor

• Model ACX1T-12A-C:
- Additional USB Type B, DB9 serial, (2) 3.5mm audio jacks

• Model ACX1T-14A-C:
- Additional USB Type B, DB9 serial, (2) 3.5mm audio jacks

• Model ACX1T-22-C:
- (2) DVI-I, (1) RJ45 CATx, (1) USB Type B

Connections — Receiver:


• All models:
- (1) DVI-I, (2) USB Type A, (1) RJ45 CATx, (1) miniUSB Type B (for Flash upgrades), (1) Power input

• Model ACX1R-11V-C:
- IR sensor

• Model ACX1R-13-C:
- (4) USB Type A for USB 2.0, (2) USB Type A for USB HID

• Model ACX1R-12A-C:
- (2) USB Type A for HID, DB9 serial, (2) 3.5mm audio jacks

• Model ACX1R-22-C:
- (2) DVI-D, (1) RJ45 CATx, (2) USB Type A


Power Supply:



• Transmitter and Receiver: 90 to 240 VAC, 47 to 63 Hz, autosensing, external power supply with IEC320 connection

Dimensions and Weight:

• Single Video Models: 103 W x 143 D x 29 H mm
• Dual Video Models: 103 W x 143 D x 43 H mm

Certifications:

• TAA-compliant

Warranty:

• 2 years Double Diamond™ Standard
