Bals 89085 socket combinations Variabox - L -
|
755,91 EUR |
|||||||||||
|
( 899,53 EUR incl. VAT ) ≈ £632.70 | ≈ $845.86 plus delivery charges: 100,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 507515 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 89085 | ||||||||||
| UPC/EAN: | 4024941206181 | ||||||||||
| Weight: | 5.104 kg | ||||||||||
| Type: | 89085 | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Bals 89085:
Standard: DIN EN 61439-2
Protection class: IP44
Housing:
high-quality, impact-resistant plastic housing (PBT)
, sealable, with external and internal fastening,
top section straight and hinged at the side
, cover screws captive, safety elements
arranged under a transparent operating flap
with user-friendly OTC mechanism (one touch close)
Device colour: lower housing section black similar to RAL 9017, upper housing section grey RAL 7035
Device height: 390 mm, device width: 230 mm, device depth: 145 mm
RDF factor: 1
InA: 48
Equipment:
2 x earthed socket 16A 230V blue IP44
2 x CEE socket 16A 400V 5p 6h IP44 inclined
Protection/protective measure:
2 x D01 1p
2 x D01 3p
on pull-out Mounting rail mounted
Cable entry/connection option:
1 x M12, 1 x M20, 2 x M40 at the top (1 x M40 open on the left)
1 x M12, 1 x M20, 2 x M40 at the bottom
Additional information:
Wired ready for connection on meter terminal block
5x25 mm² / Type: C (suitable for conductor rail)
CEE sockets with screwless, maintenance-free Quick-Connect
connection technology
Distributor without residual current device
Construction according to Z-No. Z120230
| General | |
| CEE socket outlet 16 A | 2x16A5p400V |
| CEE socket outlet 32 A | None |
| CEE socket outlet 63 A | None |
| CEE socket outlet 125 A | None |
| Number of socket outlets with protective contact | 2 |
| number of socket outlets swiss standard type 13 | 0 |
| number of socket outlets swiss standard type 15 | 0 |
| number of socket outlets swiss standard type 23 | 0 |
| number of socket outlets swiss standard type 25 | 0 |
| Other fixtures and/or empty locations | 0 |
| Protection | D0-system |
| Number of miniature circuit breakers | 4 |
| Material housing | Plastic |
| Power supply/connection possibility | 2 cables (ring line) |
| Type of mains connection | Other |
| Cable length | 0 |
| Handling | Wall mounting |
| Degree of protection (IP) | IP44 |
| Colour | Grey |
| Height | 390 |
| Width | 230 |
| Depth | 145 |
| Military model | |
Questions & answers
What is the delivery time of Bals 89085 socket combinations Variabox - L -?
The article Bals 89085 socket combinations Variabox - L - is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Bals 89085 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Bals 89085 socket combinations Variabox - L - always at the best possible price. We can give you a discount of 2% on Bals 89085 socket combinations Variabox - L - if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 3 pieces of Bals 89085 socket combinations Variabox - L - we can offer you a price of 704,89 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
