Bals Coupling Quick Connect red TN 31866, 32A 4p 6h 380-415V 50/60Hz IP67

Your rating:
Average rating
Rating for Bals Coupling Quick Connect red TN 31866, 32A 4p 6h 380-415V 50/60Hz IP67
( 4.5 / 5 ) 6 ratings
BALS 31866
This image may differ from the desired article.
203,74 EUR
( 242,45 EUR incl. VAT )
2025-10-10Delivery time on requestinfo_outline
1x Bals Coupling Quick Connect red TN 31866, 32A 4p 6h 380-415V 50/60Hz IP67
Lieske Part No.:793973
Mfg Part No: 31866
UPC/EAN: 4024941318662
Weight:0.12 kg
Graduated prices net
From piecesPrice per pieces
6191,52 EUR
12179,29 EUR
24167,07 EUR
36154,84 EUR

Product information for BALS 31866:

QUICK-CONNECT TE coupling version
32A 4p (3P+PE) 400V (380 - 415V~) 6h IP67
Frequency: 50/60Hz
Technical identification colour: bronze green RAL 6031-F9
Contact carrier/contacts: the contact carrier is made of highly heat-resistant material, the contacts are nickel-plated brass
Maximum conductor cross-section: 6.0 mm²
Housing material: polyamide
Connection technology: screwless spring clamp technology as cage clamp with Kontex contact
Cable entry: with cable gland
Device colour: cable gland bronze green RAL 6031-F9, bayonet ring bronze green RAL 6031-F9, hinged cover bronze green RAL 6031-F9, housing bronze green RAL 6031-F9
Device height: 200 mm, device width: 94 mm, device depth: 96.5 mm
Other technical properties: For cables with a Min. diameter from 11mm to max. diameter 23mm, With MULTI-GRIP TE cable gland, integrated strain relief, additional water drainage openings and locking screw, The bayonet cover is attached to the housing with a fastening strap
VG type no.: VG 96919 DS 023


Questions & answers

What is the delivery time of Bals Coupling Quick Connect red TN 31866, 32A 4p 6h 380-415V 50/60Hz IP67?

The article Bals Coupling Quick Connect red TN 31866, 32A 4p 6h 380-415V 50/60Hz IP67 is currently not in stock und muss auftragsbezogen bestellt werden.

According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of BALS 31866 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Bals Coupling Quick Connect red TN 31866, 32A 4p 6h 380-415V 50/60Hz IP67 always at the best possible price. We can give you a discount of 2% on Bals Coupling Quick Connect red TN 31866, 32A 4p 6h 380-415V 50/60Hz IP67 if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 6 pieces of Bals Coupling Quick Connect red TN 31866, 32A 4p 6h 380-415V 50/60Hz IP67 we can offer you a price of 191,52 EUR per piece. The more you buy, the cheaper the article will be.

You can also send us a price proposal for your desired quantity of Bals Coupling Quick Connect red TN 31866, 32A 4p 6h 380-415V 50/60Hz IP67 via the form price proposal. Enter your name, contact details, price and quantity you need. Our sales team will then send you a good quotation immediately.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
